[Famous Brands Raw Material Selection]
1) LED: well-know international brand, with wide viewing angle, high brightness, little attenuation, good heat dissipation, and vivid colors.
2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective phenomena, such as dark bright, virtual light and so on.
3) Power supply: industrial-strength brand, The power maximum power reserve of 20% the space, the range of voltage fluctuation is less 5%, high stability.
4) Connector: Aerial grade brands ensure the stable transmission of power and signal.
5) PCB Board: adopt 4-layer design.
6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person. The replacement of any cabinet can be done within 50 seconds.
[Cabinet details of led display screens]
[LED technical specifications]
| Indoor SMD Fixed Installed Commercial LED Displays | |||||
| Module | Pitch/mm | P3 | P4 | P5 | P6 |
| Module size/mm | 192x192 | 128x128 | 160x160 | 192x192 | |
| Pixel density (dots/m2) | 111111 | 62500 | 40,000 | 27,777 | |
| Led encapsulation | SMD2121 | SMD2121 | SMD3528 | SMD3528 | |
| Module resolution | 64x64 | 32X32 | 32X32 | 32X32 | |
| Main | Optimal viewing distance | 3-10m | 4-15m | 5-16m | 6-20m |
| View angle / ° | Horizontal 140°, Vertical 120° | ||||
| Size of cabinet/mm | 576x576 | 512X512 | 640X640 | 576X576 | |
| Driving method | 1/16 scan constant current | 1/16 scan constant current | 1/16 scan constant current | 1/16 scan constant current | |
| Refresh rate Hz/S | ≥600 | ≥600 | ≥600 | ≥600 | |
| Luminance of white balance | ≥1200 nits | ≥1500 nits | ≥1500 nits | ≥1500 nits | |
| Working voltage | 110-220 VAC/+/- 10% | ||||
| Brightness adjustment | 256 levels of each color(manually),100 levels of each olor(automatically) | ||||
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc | ||||
| Control system | Linsn/Nova (sending card, receiving cards and Hubs) | ||||
| Life span | >100,000h | ||||
| Functionless dot rate | <0.0001 | ||||
Ofrecemos un servicio integral en sus proyectos de instalación de todo tipo de pantallas led, independientemente del uso, tamaño y ubicación – interior o exterior -. Cuenta también con empresas acreditadas para ofrecer el mejor servicio de mantenimiento y postventa con la garantía Eachinled.
Del mismo modo que existen infinidad de aplicaciones y proyectos, también haymultitud de pantallas de LED. Al adquirir una pantalla LED, no sólo es necesario exigir unos elevados parámetros de calidad y fiabilidad, sino también que las características de la pantalla se adapten a las necesidades del proyecto o aplicación. Eachinled dispone de personal especializado para asesorarle en la elección y configuración de la pantalla LED.Los parámetros de particularización principales son los siguientes:
1, Superficie gráfica de la pantalla LED(m2).
2, Resolución y pitch (separación entre píxeles).
3, Relación de aspecto, o proporción entre la anchura y la altura.
4, Sistema de acceso a la electrónica interna: frontal o trasero.
5, Tipo de LED: SMD o Through Hole.
6, Uso en espacios interiores o exteriores.
7, Ubicación de la pantalla.
8, Distancia de visualización mínima y máxima.
9, Ángulo máximo de visionado, tanto en el plano horizontal como en el vertical.
[Indoor led advertising screen usage]
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time.
Warmly welcome to visit our factory in shenzhen,china.
