Specifications
hengshui guangxing screens is a professional manufacturer of Wedge Wire Screen
Wedge Wire Screen
Well screen performance is dependent on several factors, including wire and rod shape, construction, steel grade and microstructure, as well as slot accuracy over the full length of the screen. To meet the most demanding requests, Johnson Screens continues to engineer and manufacture stainless steel screens from 2 ft / 0.7 m to 40 ft. / 12.2 m. In recent years, we have more than doubled our manufacturing capacity by adding new equipment and expanding our factories.
Johnson Screens stainless steel well screens can be constructed out of 304, 304L, 316L and 904L stainless steel. Other corrosion-resistant alloys are available upon request.
Tecinical specification:
Well Screen | |
Specification (Profile wire): |
Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70 |
Specification (support rods): |
Width(mm): 2.30 3.00 3.30 3.70 |
Note: other wires and rods available upon request | |
Slot size |
0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request. |
Material: |
Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.) |
Length |
2.9 meters,3 meters,5.8 meters,6 meters. |
Diameter |
1 1/2",2",2 1/2",3",3 1/2",4",6",7",8",9 5/8",10",12",133/8",14",16" |
Screen end |
Plain beveled ends for butt welding or threaded |
|
Other sizes available on request .Deep well construction specifications available on question. Well depths :100 m, 200 m, 350 m & 600 m. | |
|
Advantage
|
Reduce energy consumption and increase water flow. Reduce erosion of entry surfaces and increase well life. Allow a uniform and efficient well development. Reduce significantly potential pump damage and subsequent maintenance costs. |
Stainless steel well screen dimension:
Advantages:
Non-clogging capabilities
Self supporting
High abreaction resistance
Large open area
Better sand filtration
Energy saving
Lowest possible cost
Long using life
Maximum flow capacity
1.Single with bubble bags and then in wooden case 2.Customized package is available
Hengshui guangxing screens co.,ltd founded in 2010,is a major manufacturer and supplier of vee wire welded products for professional end-users in the world.It is equipped with modern machines and latest technology for the manufacture of high quality welded wedge wire screens in various shapes and size .We have been recongnized for our excellence in customer solutions creativity flexibility and no nonsense mentality coupled with short delivery time and competitive price.We keep the quality according to the ISO 9001:2008 standard to let the customers satisfy.High quality and competitive price and delivering on time is our aim.We believe that we will contribute to world prosperity by establishing bridges between our country and the global world.If you have interested in our wedge wire prodducts,please contact us.
