high efficiency automatic simple structure dry mortar mixing plant

Machine Parts

Name: Biaxiai agravic mixer

Brand: SLHS2.0

Powder:15KW

Reducer type:XWD8

Machine Parts

Name: Bucket elevator
Brand: TDTG36/28
Powder:5.5KW

Machine Parts

Name: Dust collector
Brand: TYDMC18
Powder:2.2KW

Fan:Y4-72

Machine Parts

Name: Finished products silo
Powder:5.5KW

Capacity:2.5m³

Product Application

Dry mortar, also known as ready-mixed mortar.screening process is dried aggregate (eg quartz sand), inorganic cementitious materials (such as cement) and additives (such as polymers), etc. By a certain percentage of a physical mixture kinds of granular or powdered material. In bags or in bulk transport to the site, the material after mixing with water can be used directly. Also known as the mortar dry powder, dry blend, mix dry powder.

 Automatic energe-saving dry mortar production line is designed based on the traditional mixer, is added a material conveying system, a storage bin and an automatic filling machine. The well-mixed materials will go into the storage bin via material conveying pipe, and the mixer may be feed consecutively and work continuously in flow line production, but the equipment is not over 4 meters high, thus solving the problem of heightening the workshop. Moreover, it may realize automatic metering and filling, hence, it may not merely save the time and energies but also may be more accurate. Requiring little investment, but it may load, weight and package the materials automatically; no wondering, it is a simple but practical production line.

Main features

1) Ingenious materials distribution system supports a bucket elevator distributive operations, thus               avoiding the waste of resources.

2) The sensor data in real-time feedback to ensure that all material measurement precision.

3) Intelligent continuous operation, 3-5 workers can be done, small dust, high efficiency, Nissan up

    to 80-120 tons;if required, high capacity, can increase the number of weightlessness mixer,

    such as the configuration of two agravic mixer, daily production can reach more than 200 tons.

4) Multiple mixing procedure, uniformity, and no material segregation phenomenon.

5) The effect of dust, low noise, in line with national environmental requirements.
