Help CenterChina No.1 Laser Bed Acrylic Co2 Laser Cut Machine 1325 With 150w RECI Co2 Laser Tube
Related Products
-
Acrylic Co2 Laser Cut Machine 1325 With 150w RECI Co2 Laser TubeUS$ 7,900 - 9,900MOQ: 1 Set -
Large Scale Co2 Wood Stone Laser Engraving Cutting Machine With High AccurancyUS$ 8,100 - 12,000MOQ: 1 Set
-
Best Dongguan China Cheaper Crystal Acrylic Laser Cutting Bed CO2 150W Reci TubeUS$ 10,000 - 12,000MOQ: 1 Set
-
Distributors Wanted for Laser Balsa Wood Cutting MachineUS$ 8,000 - 11,200MOQ: 1 Set
-
20 Years Use Without Deformation Euro Laser Cutting Machine HS-B1525US$ 8,500 - 34,000MOQ: 1 Set
Specifications
1300*2500MMco2 laser tube with step motor
100% dust can be extracted
CE,FDA certificate
high precision as ball screw
600°C heat treatment
24 hours cooling in the oven
8 meters gantry milling
20 years usage without deformation.
HS-B1325 LASER MACHINES TECHICAL PARAMETER
Model |
HS-B1325 |
Laser Tube Power |
135W Co2 laser |
Gross Weight |
1200kg |
Net Working Place |
1300 x 2500 mm |
Packing Size |
3670×2070×1380mm. |
Media Dimensions |
1730 x 1180 x 1060 mm |
Interface |
USB |
Cutting Thickness |
25mm acrylic cutting,18mm wood cutting |
Standart Lens |
2 inch |
Highest running speed |
48m/min |
Controlling Motor |
Step Motor |
Graphic formats supported |
PLT,DST,DSB,AI,DXF,BMP,JPG |
Power |
220V, 6A, 50/60Hz |
Working Plate |
Honeycomb |
Compresor |
Avoid to flameable and obtain to cooling |
Gross Power |
≤ 1500W |
Repeated Position Precision |
±0.01mm |
Cutting precision |
±0.1mm.Cutting D: 2mm cirles at speed of 15mm/s. |
Focus Lens |
100mm |
water chiller |
CW5000 water chiller |
Min.Media Thickness |
2mm circle fast speed cutting |
Running belt |
60mm Italian |
Feature:
1)Italy imported steel-strip belt; precise gear wheels transmitting technology.
(The gear wheels move instead of the belt, to prevent sawtooth caused by vibration from the long belts.)
2) Patent upper blowing system together with normal lower blowing systems;
Upper blowing system Two-section lower blowing system:
3) Firm machine body heat treatment, high temperature annealing to eliminate its machine stress, quadrate pipes jointing and gantry milling. Cutting precision: ±0.1mm
4) . Precision as high as ball screw guide laser bed, ensures 20-year life without deformation.
by going through precise processing as bellows: A: machine body heat treatment; B:high temperature annealing to eliminate its machine stress; C: quadrate pipes jointing and gantry milling.
A: 600°C heat treatment, 24 hours cooling in the oven, 8 meters gantry milling, accurate argon shielded arc welding, to make sure 20 years usage without deformation.
8 meters gantry milling: Accurate argon shielded arc welding:
Polishing and painting Profiling
B: Use the collimator to install and adjust guide rail, precision: 0.01mm. Synchronizing wheels bouncing testing to avoid saw tooth when cutting and precision reaches 0.02mm.
C: The only one small power laser machine manufacturer to use 5 steps of laser tube testing technology.
a. Laser spot testing
b. Power testing
c. Lifespan testing
d. Air pressure testing
e. On and off testing
D: Aging testing: 3 whole days and nights, running at speed of 400mm/s.
Precision of HS-B1325:
Remarkable high precision and applications:
1. Unique transmitting system, one-side belt driven by 3 bearing wheels, reducing strength consumption.
2. Cutting precision: ±0.1mm.
Cutting D: 2mm cirles at speed of 15mm/s.
Cutting 1.1 *1.1m rectangle with same length of diagonals
3.Applications and specifications:
Precisely cutting 25mm thick acrylic and 12mm thick wood.
1) High-value-added LGP industry, profit margin is enhanced.
2) Signs acrylic letters up to 25mm.
3) 12mm thick plywood, speed.
Cutting Samples:
4. Specifications:
1) Italy imported 50mm wide steel-strip belt, precise gear wheels transmitting technology;
2) Upper and lower double blowing systems, 3 sets of 370W exhaust blowers for each machine;
1) Firm machine body heat treatment, high temperature annealing to eliminate its machine stress, quadrate pipes jointing and gantry milling;
2) Unique transmitting system, one-side belt driven by 3 bearing wheels, reducing strength consumption;
3) Cutting precision: ±0.1mm.Cutting D: 2mm cirles at speed of 15mm/s.
Machine Details:
Scarlett Ho
Foshan Beyond Laser Technology Co., Ltd.
Tel: +86 757 89919766
Website:
www.cnfshsl.en.china.cn
