P5 Outdoor Full Color led video wall Fixed With SMD Type

Module

NO.

Item

Parameter

1

Pixel pitch

5mm

2

Module density

40000pixels/sq.m

3

Module dimension

320mm*160mm

4

Module resolution

64*32dots

5

LED encapsulation

SMD 3in1(2727)

6

Pixel configuration

1R1G1B

Cabinet

1

Dimension

960mm*960mm*80mm

2

Physical resolution

320*160dots

3

Module quantity

18PCS

4

Weight

28kg/PCS

5

Material

Die-casting aluminum

6

Driving method

Constant current+1/8 scan

7

Brightness

>6000 cd/sq.m

8

Max power consumption

1,000W/sq.m

9

Average consumption

500W/sq.m

10

Frame frequency

60HZ

11

Refresh frequency

>1200HZ

12

Gray level

16384~65536

13

Ingress protection

IP65

14

Input voltage

AC100-120V or AC200-240V

15

Viewing angle(H/V)

120°/120°

16

Best viewing distance

>5m

17

Working environment

Temperature: -20℃~ 60℃

 18

 Control system

Humidity:10%~90%RH

Synchronous /Asynchronous Control system

19

Display function

Videos,animation,pictures,text,etc.

20

Certificate

CE Certification (SGS)
