Specifications

DKS15D / DKS17BD Mitsubishi Triton ML Mitsubishi Zinger 2.4 PV4 pulley ac compressor 506012-2061A 5060122061A MN123627

Our factory can produce many kinds of auto Air Conditioner Compressors with good quality and one year quality warrantee.



DKS15D / DKS17BD Mitsubishi Triton ML Mitsubishi Zinger 2.4 PV4 ac compressor









Specification:

Model number: INTL-XZC594

Car name: Mitsubishi Triton ML  Mitsubishi ZINGER 2.4

Compressor type:DKS15D /  DKS17BD

Year Model:2006-2010

Grooves: PV4

Voltage: 12V

Clutch DIA: 123mm



Special Notes:



OEM:

506012-2061A

5060122061A

Details



2006-2010 Mitsubishi Triton ML 2.4L 4CYL 4G6 ENG

2006 Mitsubishi Triton ML 2.4L

2007 Mitsubishi Triton ML 2.4L

2008 Mitsubishi Triton ML 2.4L

2009 Mitsubishi Triton ML 2.4L

2010 Mitsubishi Triton ML 2.4L



2005-2008 Mitsubishi ZINGER 2.4

2005 Mitsubishi ZINGER 2.4

2006 Mitsubishi ZINGER 2.4

2007 Mitsubishi ZINGER 2.4

2008 Mitsubishi ZINGER 2.4









Our Factory

Basic Requirements when servicing an A/C system:



1, The Accumulator or Filter Drier should always be replaced when the Air Conditioning System is opened. For warranty Purposes buyer must show evidence of receiver/drier replacement. In some vehicles the drier comes attached to the condenser so it must replaced as well



2. A/C system must be clean and free of debris and contaminants. In most cases components can be flushed; however in some instances it may be necessary to replace the condenser or other items.



3. Orifice tube must be replaced; expansion valve must be inspected and replaced if dirty or defective.



4. Correct amount and type of oil must be used. Please refer to the OE manufacturer for this information.



5. Prior to refrigerant charging, full vacuum must be done for a minimum of 45 minutes. In humid climates or during cooler days, this time should be increased to effectively remove air and boil off moisture.



6. The Orifice Tube, if equipped, should always be replaced and the Expansion Valve, if equipped, should at least be inspected for proper operation if not replaced
