Specifications

Our factory can produce many kinds of auto Air Conditioner Compressors with good quality and one year quality warrantee.

SD7H13 706 8902 ac compressor pv8 pulley

Specification:

Model number: INTL-C124

Car name: Universal

Compressor type: SD 7H13 706

Clutch DIA: 119mm

Grooves: PV8

Voltage: 12V

Special Notes:

OEM:

SD7H13 8902
SD706 8902
8902
SD7H13

7H13

706

Basic Requirements when servicing an A/C system:

1, The Accumulator or Filter Drier should always be replaced when the Air Conditioning System is opened. For warranty Purposes buyer must show evidence of receiver/drier replacement. In some vehicles the drier comes attached to the condenser so it must replaced as well

2. A/C system must be clean and free of debris and contaminants. In most cases components can be flushed; however in some instances it may be necessary to replace the condenser or other items.

3. Orifice tube must be replaced; expansion valve must be inspected and replaced if dirty or defective.

4. Correct amount and type of oil must be used. Please refer to the OE manufacturer for this information.

5. Prior to refrigerant charging, full vacuum must be done for a minimum of 45 minutes. In humid climates or during cooler days, this time should be increased to effectively remove air and boil off moisture.

6. The Orifice Tube, if equipped, should always be replaced and the Expansion Valve, if equipped, should at least be inspected for proper operation if not replaced
