outstanding Air Compressor for sale
Especially design for PET blowing machines
Our products all adopt original import pressure controller. The Air-cooling Series are equipped with patent and high efficiency heat exchanger. All levels of heat exchanger efficiency can reach 98%. (After cooling, the compressed air at normal temperature)
To prevent blocked heat exchanger from affecting heat dissipating, we increase the cooling area of heat exchanger to be 2.5 times, which is especially suitable for high temperature fields. For three-stage compressor, we all use differential compression in two or three stage compression. During the compression process that the same piston finish two and three stage air inlet and outlet, the cancelled piston force on the end face of two and three stage piston can reach 30%, which is more power saving.
Over the years, Water-cooling Series High Pressure Air Compressor produced by our company, owing to its over long service life (5 years without faults in normal situation), has been popular in every corner of our country and received good comments from many customers! Our Air-cooling High
Pressure Air Compressors, because of their patented heat dissipating technology and with higher standard than that of water-cooling series, have been well approved by our customers and successfully promoted.
Technical Data Sheet:
Model |
|
WF1.25/400B |
|
Free air delivery |
m3/min |
1.25 |
|
Discharge pressure |
Bar |
400 |
|
Cooling mode |
|
Air cooling |
|
Driving mode |
|
Belt driven |
|
Power supply |
V/Ph/Hz |
380V 3Ph 50Hz as standard, also can be changed as customers' requirement. |
|
Motor power |
KW/HP |
30/45 |
|
Type |
|
Type W 3 cylinder 2 stage |
|
No. of cylinder |
|
125*2/65 |
|
External dimensions |
L |
mm |
1650 |
W |
mm |
650 |
|
H |
mm |
1450 |
|
Weight |
Kg |
1300 |
|
Dream(Shanghai) Compressor Co., Ltd., founded in 2005, is a Sino-German high-tech enterprise in research, development, production and sales. Our company is located in Songjiang district, Shanghai, covering an area of ten thousand square meters with more than 300 employees. We have set up offices in the major provinces and cities. We are not only provide the high-quality air compressors from minimum 7.5Kw to maximum 355Kw, but also provides matching processing equipment of compressed air.We will wholeheartedly serve you.
