Type 41 EL Discos De Corte for metal and steel

Specifications

Discos de corte
Material:Brown alumina oxide
Sharp,give clean cut
High strength add safety
Use cutting metal,stainless steel

Type 41 Discos De Corte for metal and steel

Factory Advantages

1.Near to raw materials region,low labor costs,so lower production cost,competitive price,

2.Locate in the center of China,low and almost same transport costs to any China main port,

3.Advanced technique,

4.More than 10 years production experience,

5.Strict quality testing,good after-sale service,

6.ISO9001:2000 certificate

7.Abundant export experience

8.Accept OEM brand,

9.Small order is accepted.

10.Free samples to test quality.

Raw Materials

High hardness abrasive:ensure cutting sharp sex

Brown aluminium Oxide

High quality reinforced net:ensure the security of the power 355cutting machine

High quality adhesive resin:ensure good durable performance

Powder phenolic resin:Good technological efficiency,a smaller forming density,greater abrasives structure.

Product:

Size(mm)	Size(inch)	Shape	Description(A46#QBF)	Colour	Speed(r.p.m)	Speed(m/s)
115x1.2x22.2	41/2x3/64x7/8	flat	1.Material:Aluminium oxide, 2.Grit size 46#, 3.Hardness(1):Q 4.Bonding agent:resin 5.Reinforced net:two fiberglass nets	Brown,black	13300	80

(1)Generally,please chose reasonable hardness cutting wheel to reduce its attrition wear.These factors can affect the cutting wheel hardness:The amount of resin bond to join,Forming density of abrasive,Sintering temperature and sintering temperature etc.

Application:

Professional cutting metal,general steels,ferrous metal stainless steel, alloy steel, quench steel, tool steel and hard iron casting metal.

Feature:

1.Propritary AO material mix ensures durable long life,

2.Imported resin bonded makes our wheel stronger,

3.The two high strength reinforced glass fiber nets,very hard,

4.Very fast and smooth cutting performance,

5.Clean cutting,better surface finish,

6.Small electric current,workpiece cross section burns lightly,

7.No vibration and no bouncing on work place,

8.The cutting dust is light,the working conditions are good,

9.High cutting efficiency,excellent durability

Domestic leading molding equipment:ensure the stability of the product performance

Test thickness



Performance testing site

The cutting workpiece:D12mm 201 Stainless steel

After cutting 10 times,the diameter of the disc:94mm

After cutting 20 times,the diameter of the disc:85mm

After cutting 30 times,the diameter of the disc:70mm

Cutting result

The test report

test result is one piece of 105*1.2*16 mm ,cuting finished.
Size	cutting object	cutoff quantity	efficiency SEC/cutoff	quality
Φ105×1.2×16mm	Φ10mm SS rod	85	4	A
Φ105×1.2×16mm	Φ10mm SS rod	55	5	B
Φ105×1.2×16mm	Φ10mm SS rod	27	7	C

Cautions:

1.Do visually inspect all wheel before mounting for possible damage.

2.Do make sure operating speed of machine, does not exceed speed marked on wheel,its blotter or container.

3.Do check mounting flanges for equal size,relieved as required and correct diameter.

4.Do be make sure work rest is properly adjusted on bench,pedestal and floor stand grinder.

5.Do always use safety guard that covers a mimimum of one-half the abrasive wheel.

6.Do allow newly mounted wheel to turn at operating speed,with guard in place,for at least one minute beforerinding.

7.Do ture off coolant before stopping wheel to avoid creating an out-of-balance condition.

Safety Recommendatio

1.Wear protective goggles;

2.Wear protective gloves;
3.Wear ear protectors;
4.Wear dust respirators;
5.Observe safety recommendations.

Packing:

1.During transport,please load and unload carufully to prevent the crack and shock.Ensure packing without damage.

2.During storage,put the wheels horizontally,donot touch the floor directly.

3.Should prevent moisture and direct sunlight,keep the warehouse shady and ventilated.The warehouse's temperature can not be less than 5 degrees.

Dimension mm	Dimension inch	Speed r.p.m	Speed m/s	G.Weight kg	Dimension L*W*H(mm)	Box Qty
						Pcs/ CTN
100x1.2x16	4x3/64x5/8	15200	80	20	330x250x230	800
115x1.2x22.2	41/2x3/64x7/8	13300	80	23	500x260x195	800
125x1.2x22.2	5x3/64x7/8	12000	80	21	410x280x185	400
150x1.2x22.2	6x3/64x7/8	10200	80	20	330x330x185	400
180x1.2x22.2	7x3/64x7/8	8500	80	23	390x390x145	300
230x1.9x22.2	9x5/64x7/8	6600	80	19	490x250x140	100
