Help CenterNormal Steel Cutting Wheel for Angle Grinder
Related Products
-
350mm Abrasive Stationary Saw Blades Cutting Wheels Big DiameterUS$ 0.85 - 1.5MOQ: 3000 Pieces -
105x1.2x16mm Abrasive Cut off Wheels,cutting Wheel,cutting Disc for Metal&stainless SteelUS$ 0.01 - 0.1MOQ: 1 Piece
-
350x2.5x25mm Abrasive Cut off Wheels,cutting Wheel,cutting Disc for Metal&stainless SteelUS$ 0.01 - 0.1MOQ: 1 Piece
-
350x2.5x25mm Abrasive Cut off Wheels,cutting Wheel,cutting Disc for Metal&stainless SteelUS$ 0.9 - 1MOQ: 1 Piece
-
Manufacturers 5" Inch Resin Bonded Cut off Wheel for Angle GrindersUS$ 0.16 - 0.28MOQ: 10000 Pieces
Specifications
1.Made by aluminum oxide2.Two reinforced mesh,safety
3.Sharp,clean cut action
4.Longer service life
5.Cutting normal steel
Factory Advantages
1.Near to raw materials region,low labor costs,so lower production cost,competitive price,
2.Locate in the center of China,low and almost same transport costs to any China main port,
3.Advanced technique,
4.More than 10 years production experience,
5.Strict quality testing,good after-sale service,
6.ISO9001:2000 certificate,
7.Abundant export experience,
8.Accept OEM brand,
9.Small order is accepted,
10.Free samples to test quality.
Raw Materials
High hardness abrasive:ensure cutting sharp sex
High quality adhesive-resin:ensure good durable performance
Powder phenolic resin:Good technological efficiency,a smaller forming density,greater abrasives structure.
High quality reinforced net:ensure the product use security
Product:
| Size(mm) | Size(inch) | Shape | Description(A36#QBF) | Colour | Speed(r.p.m) | Speed(m/s) |
|
125x3.0x22.2
|
5x1/8x7/8 | flat |
1.Material:Aluminium oxide 2.Grit size:36#, 3.Hardness(1):Q 4.Bonding agent:resin 5.Reinforced net:Two fiberglass nets,two black papers |
Black | 12200 | 80 |
(1)Generally,please chose reasonable hardness cutting wheel to reduce its attrition wear.These factors can affect the cutting wheel hardness:The amount of resin bond to join,Forming density of abrasive,Sintering temperature and sintering temperature etc.
Feature:
1.Specially treated Aluminium oxide grain for extended life and fast cut,
2.Imported resin bonded makes our wheel stronger,
3.Two reinforced fiber glass nets makes our disc more strength,
4.Sharpness,more powerful capacity,
5.Extremely precise and straight cutting,
6. Super cooling cutting-won”t burn workpiece surface,
7.No vibration and no bouncing on work place,
8. Minimum of the dust,possess superior abrasion resistance,
9.Lowest power consumption,outstanding service life.
Usage:
ideal for cutting metal and steel,like general metal,hard metal,sheet metal, ferrous metal,nonferrous metal,iron,angle iron,normal steel,steel sheet,steel bar,steel pipe and so on
these industry maybe use this type wheel
1.investment castings,
2.steel ingotsand bar manufacturing,
nstruction,
4.foundries and allied industry,
5.pipe manufacturing,
6.fabrications
Automatic production line:ensure the stability of our products
Performance testing site:
Cutting result
| Size | Cutting Object | Cutoff Quantity | Efficiency SEC/cutoff | After Cutting Surplus |
| Φ230×3.0mm | 5×5×0.3cm angle iron |
10 | 10 | Φ220mm |
| Φ250×2.0mm | 5×5×0.3cm angle iron |
20 | 15 | Φ245mm |
| Φ300×2.5mm | 5×5×0.3cm angle iron |
20 | 9 | Φ283mm |
| Φ350×2.5mm | 5×5×0.3cm angle iron |
20 | 7 | Φ336mm |
Cautions:
1.Do visually inspect all wheel before mounting for possible damage.
2.Do make sure operating speed of machine, does not exceed speed marked on wheel,its blotter or container.
3.Do check mounting flanges for equal size,relieved as required and correct diameter.
4.Do be make sure work rest is properly adjusted on bench,pedestal and floor stand grinder.
5.Do always use safety guard that covers a mimimum of one-half the abrasive wheel
6.Do allow newly mounted wheel to turn at operating speed,with guard in place,for at least one minute beforerinding.
7.Do ture off coolant before stopping wheel to avoid creating an out-of-balance condition.
Safety Recommendatio
1.Wear protective goggles;
2.Wear protective gloves;
3.Wear ear protectors;
4.Wear dust respirators;
5.Observe safety recommendations.
Packing:
1.During transport,please load and unload carufully to prevent the crack and shock.Ensure packing without damage.
2.During storage,put the discs horizontally,donot touch the floor directly.
3.Should prevent moisture and direct sunlight,keep the warehouse shady and ventilated.The warehouse's temperature can not be less than 5 degrees.
METAL |
NAME |
SIZE |
SPEC |
MAX OPERATING SPEED |
BOX QTY |
||
|
|
mm |
inch |
|
m/s |
rpm (min-1) |
|
Type-41 |
PER CUT |
100 x 3 x 16 |
4 x 1/8 x 5/8 |
A46 |
80 |
15,200 |
400 |
|
|
115 x 2.5 x 22.23 |
4 - 1/2 x 3/32 x 7/8 |
A36 |
80 |
13,300 |
400 |
|
|
115 x 3x 22.23 |
4 -1/2 x 1/8 x 7/8 |
|
|
13,300 |
300 |
|
|
125 x 2.5 x 22.23 |
5 x 3/32 x 7/8 |
|
|
12,200 |
300 |
|
|
125 x 3x 22.2 |
5 x 1/8 x 7/8 |
|
|
12,200 |
300 |
|
|
180 x 3 x 22.23 |
7 x 1/8 x 7/8 |
|
|
8,500 |
100 |
|
|
230 x 2.5x 22.23 |
9 x 3/32 x 7/8 |
|
|
6,600 |
100 |
|
|
230 x 3 x 22.23 |
9 x 1/8 x 7/8 |
|
|
6,600 |
100 |
|
|
300 x 3 x 25.4 |
12 x 1/8 x 1 |
A30 |
80 |
5,100 |
25 |
|
|
350 x 3 x 25.4 |
14 x 1/8 x 1 |
|
|
4,400 |
25 |
