Specifications
small garden tractor loader backhoe kubota tractor backhoehigh quality
attractive design
small garden tractor loader backhoe kubota tractor backhoe
Hydraulic backhoe with movable frame and mechanical lock, independent hydraulic outrigger feet with safety valve, main joints equipped with pins and bushings made of tempered cemented steel, and mounting kit for farm tractor.
1. BH5 without PTO pump
2. BH5R with PTO pump
3. With standard 200mm bucket.
4. Optional 250mm, 300mm, 400mm buckets.
Model |
BH5 | BH5R |
3-Point Linkage: |
Cat. 1 & 2 | Cat.1&2 |
(A) Working Length: |
2900mm | 2900mm |
(B) Digging Depth: |
1550mm | 1550mm |
(C) Extend Height: |
3170mm | 3170mm |
Unload Height: |
2000mm | 2000mm |
Leg Spread: |
1700mm | 1700mm |
Swing Angle (boom): |
180 degrees | 180 degrees |
Work Pressure (bar): |
16mpa | 16mpa |
Max. Pump Capacity: |
NO | 14L(L/min@540rpm) |
Tank Capacity: |
NO | 12L |
Sliding Width: |
840mm | 840mm |
Weight with Bucket: |
550kg | 580kg |
