small backhoe loader spare parts backhoe for farm tractor Quality Choice

Backhoe For Farm Tractor packed in steel crate or according to customer requirement

Specifications

small backhoe loader spare parts backhoe for farm tractor
with CE
independent hydraulic optional parts

            small backhoe loader spare parts backhoe for farm tractor





small backhoe loader spare parts backhoe for farm tractor
with CE
independent hydraulic optional parts





Descriptions:





It's ideal for digging irrigation trenches, breaking up rocky soil, piping preparation, channelling rainfall runoffs and roadsides, planting and relocating trees.



1. Suited for 20-40hp tractors



2. With 12'' Bucket



Optional:

1. Hydraulic system ( PTO gearbox & PTO pump & oil tank )



2. 14'' ,16'', 18'' bucket



Specifications:



Model		BH175		BH195
Specification		Inch	Metric	Inch	Metric
Tractor HP		25-30HP		30-45HP
3-point Linkage		Cat-1		Cat-1
Structure Weight		1060lb	480kg	1100lb	500kg
A	Digging Depth(two foot flat bottom)	5.74’	1750mm	6.4’	1950mm
B	Reach from center line of Swing pivot	8.53'	2600mm	9.51’	2900mm
C	Loading Height(bucket at 60°)	5.64’	1720mm	6.03’	1840mm
D	Transport Height(maximum)	6.03’	1840mm	6.75’	2060mm
E	Extend Height	9.41'	2870mm	10.2'	3110mm
F	Loading Reach(bucket at 60°)	3.11’	950mm	3.87'	1180mm
G	Transport Overhang	3.54'	1080mm	3.64'	1110mm
H	Undercut	2.4'	730mm	2.72'	830mm
I	Bucket Rotation	180°		180°
J	Stabilizer Spread(up position)	4.3’	1310mm	4.3’	1310mm
K	Stabilizer Spread(down position)	4.3’	2100mm	6.9’	2100mm
L	Swing Arc	180°		180°









Model		BH225		BH255
Specification		Inch	Metric	Inch	Metric
Tractor HP		45-60HP		60-80HP
3-point Linkage		CAT-1&2		Cat-1&2
Structure Weight		1280lb	580kg	1370lb	620kg
A	Digging Depth(two foot flat bottom)	7.38’	2250mm	8.36’	2550mm
B	Reach from center line of Swing pivot	10.5’	3200mm	11.8’	3600mm
C	Loading Height(bucket at 60°)	3.66’	1930mm	7.25’	2210mm
D	Transport Height(maximum)	6.98’	2130mm	8.13'	2480mm
E	Extend Height	10.62’	3240mm	11.77’	3590mm
F	Loading Reach(bucket at 60°)	3.74’	1140mm	4.46’	1360mm
G	Transport Overhang	4’	1220mm	4.16’	1270mm
H	Undercut	1.54’	470mm	1.7’	520mm
I	Bucket Rotation	180°		180°
J	Stabilizer Spread(up position)	4.3’	1310mm	4.3’	1310mm
K	Stabilizer Spread(down position)	7.67’	2340m	7.67’	2340mm
L	Swing Arc	180°		180°









 New Item !!!



Details:









Changzhou Farmer Helper Machinery Co.,Ltd (FMH)  is established in 2009,located in Benniu Industrial Park,Changzhou,Jiangsu,China.



With its strong technique power,complete set of manufacture equipments and experimental devices,advanced CAD R&D means, the company has complete production capaicty from cutting,profiling,welding,maching,paiting to packing.



 FMH has aleady manufactured a full range of high quality implements for the small to medium-sized tractor owners across the world,Such as Front End loader, Backhoe, Mower, rotary tiller, Wood Chipper, Log Splitter, Post Hole Diggers. more than 50 serials and more than 150 models of various implements.





 Contact Me !





1.Q: Full price list for these products



 A:If you need the price list for these products, please notify the product model so that i can quote you accordingly.



Please understand we have a very wide product range, we don't usually offer full products price list.



2. Q: Main market



A:Western Europe and Australia.



3. Q: Export quantity



A:20-30 units of 40ft container per month.



 4. Q: Business terms



A:Shipment time: 45days after your payment



    Shipment: By sea



    Loading port: Shanghai port, China



    Destination port: ...To be advised



    Payment: By bank transfer



    Warranty: 1 year



 5. RE: CE



A: Most of our products are certified by CE.



 6.RE: Client for reference



A:GEO is our main dealer in Europe.



 7.Q:Sample test



A:Now our agri machines are exported in large quantity.



If you need one sample for test, we advise you to get this sample from the domestic dealers.



If you want to get from us directly, usually we advise to order at least one pallet per product.



 8.Q:Why choose FMH for cooperation?



A:FMH is professional Agri&Forestory machine manufacturer in China. Comparing with our competitors, we have much more advantages as follows:



 1.More Professional Sales staffs to guarantee the better service:14 staffs



2. More agri machines for your choice:198types One-stop total solution.



3. More New products into your range to avoid price competion:every momth



4.Larger quantity production and shipment:20X40ft containers per month and go on increasing.



5.More advanced CNC processing equipments to guarantee the higher quality :2units of advanced laser cutting machines and more than 50units of CNC metal precessing machines



6.Better quality to guarantee better Credit.



7.Faster delivery time:only45days



8.More stick quality checking before shipment.



9.More reasonable after-sales service terms.



10.More famous brand: FMH;



11.Largest manufacturer of tractor mower;



12.Largest manufacturer of wood chipper;



 9.Q:- Can we mix different models together?



A:You may mix different products or models in 1x20ft or 1x40ft container but in order to make the best use of container room, usually we advise to order a pallet of the same product.



 10.Q:-How about our agri machines fit with other brand tractors?



A:-Our 3 point system and PTO are designed to international standards and will accept all class 1 - 3 point implements.



 11.Q:- Can I put my brand name on your agri machines instead of your brand name?



A:- Yes. Many dealers sell our agrimachines with their own brand name. Some have design modifications to meet their unique needs.



 12.Q:- How do I visit you and the factory?



A:- You are welcomed to visit us and our factory at your convenience.



You can fly to Shanghai air port and then come from Shanghai railway station to Changzhou city by Shanghai Nanjing high-speed railway, only one hour’ trip.



Also you can fly to Changzhou air port from Chinese other air ports.



We can pick you up at Changzhou Railway Station or Changzhou airport and bring you to our factory .



 Let us know your schedule in details so we can arrange everything for you.



 13.Q:- How can I become a dealer in my area?



A:- If you are qualified, you may apply for a dealership. We choose reliable partners for a long term business cooperation.



 14.Q:- Can I get an exclusive right for your agri machines in some territories?



A:- Usually we do not grant the exclusive agent for all of our agri machines in one country market because one client could not sell all our machines.



But we could grant the exclusive agent for one or two of our products in one country according with the sales quantity.
