2015 New Style Used Towable Mini Backhoe for Sale

US$ 1,800 - 2,200 MOQ: 1 Unit

Key Specifications

Condition:

New

Application:

towable backhoe

Place of Origin:

Jiangsu, China

Changzhou Farmer-Helper Machinery Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application towable backhoe

Place of Origin Jiangsu, China

Brand Name FMH

Model Number BHM

Dimension(L*W*H) 180*133*112/2

Weight 580kg

Features CE towable backhoe small garden towable backhoe tractor towable backh

Certification CE,ISO9001

Warranty 3 year

After-sales Service Provided No overseas service provided

2015 new style used Towable mini Backhoe for sale

Product Description

BHM Backhoe

1.the backhoe includes PTO pump,gearbox&oil tank

2. With standard 300mm bucket.

3. Optional 400mm, 500mm,buckets.

Model		BHM175		BHM195
Specification		Inch	Metric	Inch	Metric
Tractor HP		25-30HP		30-45HP
3-point Linkage		Cat-1		Cat-1
Structure Weight		1060lb	480kg	1100lb	500kg
A	Digging Depth(two foot flat bottom)	5.74’	1750mm	6.4’	1950mm
B	Reach from center line of Swing pivot	8.53'	2600mm	9.51’	2900mm
C	Loading Height(bucket at 60°)	5.64’	1720mm	6.03’	1840mm
D	Transport Height(maximum)	6.03’	1840mm	6.75’	2060mm
E	Extend Height	9.41'	2870mm	10.2'	3110mm
F	Loading Reach(bucket at 60°)	3.11’	950mm	3.87'	1180mm
G	Transport Overhang	3.54'	1080mm	3.64'	1110mm
H	Undercut	2.4'	730mm	2.72'	830mm
I	Bucket Rotation	180°		180°
J	Stabilizer Spread(up position)	4.3’	1310mm	4.3’	1310mm
K	Stabilizer Spread(down position)	4.3’	2100mm	6.9’	2100mm
L	Swing Arc	180°		180°

Model		BHM225		BHM255
Specification		Inch	Metric	Inch	Metric
Tractor HP		45-60HP		60-80HP
3-point Linkage		CAT-1&2		Cat-1&2
Structure Weight		1280lb	580kg	1370lb	620kg
A	Digging Depth(two foot flat bottom)	7.38’	2250mm	8.36’	2550mm
B	Reach from center line of Swing pivot	10.5’	3200mm	11.8’	3600mm
C	Loading Height(bucket at 60°)	3.66’	1930mm	7.25’	2210mm
D	Transport Height(maximum)	6.98’	2130mm	8.13'	2480mm
E	Extend Height	10.62’	3240mm	11.77’	3590mm
F	Loading Reach(bucket at 60°)	3.74’	1140mm	4.46’	1360mm
G	Transport Overhang	4’	1220mm	4.16’	1270mm
H	Undercut	1.54’	470mm	1.7’	520mm
I	Bucket Rotation	180°		180°
J	Stabilizer Spread(up position)	4.3’	1310mm	4.3’	1310mm
K	Stabilizer Spread(down position)	7.67’	2340m	7.67’	2340mm
L	Swing Arc	180°		180°
