Heating thermostat;room thermostat;Output Convertible; relaygas boiler thermostat.
Features:
1) Heating / cooling control;
2) Easy operation and intuitive display
3) Delay-time On / Off function;
4) The temperature difference between off and on is adjustable
5) Allowable to calibrate the temperature display;
6) Allowable to connect the external temperature sensor (Optional: NTC 100K). Outdoor temperature display provided.
7) Display adjustable between room temperature, outdoor temperature and preset temperature.
8) Display adjustable between C and F.
9) Antifreeze when turn off.
10) Allowable to set the highest temperature of heating and the lowest temperature of cooling.
11) Three transmission modes for wireless
12) Multiple fault detection and display functions.
Parameter
- Power: 220V AC (±10%) 50 Hz or two LR6 1.5V alkaline batteries
- Contact capacity: 16A/250V
- Range of temperature display: 0÷45 C/32÷113 F
- Range of temperature setting: 5÷35 C/41÷95 F
- Display accuracy: 0.1 (1)
- Probe sensor: NTC (100K) 1%
- Service life of relay: Switching times not less than 100,000 times
- Protection level: IP20
- Insulating condition: Normal environment
- Working environment temperature: -18÷50 C /0÷122 F
- Frequency: 433MHz (WH501RF/MRF)
- Wireless transmission distance: Indoor 10m-20m; outdoor 100m-200m
- Dimension (mm): 86H*86W*12D
- Installation:On batter seat installation
- Control of family air-condition and central air-condition;
- Control of wall-mounted boiler
- Control of Thermal Actuator or electromagnetic valve
- Control of water pump;
- Control of fan coil;
- Ventilation control.
