Help CenterGuard Rail Roll Forming Machine
Related Products
-
Metcoppo Step Tile Rollforming MachineUS$ 60,000 - 70,000MOQ: 1 Set -
Metal Processing MachineryUS$ 25,000 - 40,000MOQ: 1 Set
-
Fully Automatic Stacking MachineUS$ 75,000 - 150,000MOQ: 1 Set
-
Fully Automatic Wrapping MachineUS$ 55,000 - 75,000MOQ: 1 Set
-
Metal Roofing Corrugated SheetsNegotiableMOQ: 2000 Sheets
Specifications
Fully automatic Guard rail roll forming machineThe line consisit of :
- Fully automatic decking forming machine
- Hydraulic de coiler with coil car 5 MT coil
- Exit table 3 meter x 02sets.
Technical data :
- Electric components( Touch panel, PLC) : Siemens Gemany / USA / Japan
- Hydraulic components : Yuken-Japan .
- Motor power : 22Kw
- Machine dimension : L xW x H ( 9m x 1.5m x1.6m)
- Machine weight : 10 tons
- Rollers station : 13 stations with gearboxes
- Gearbox : Made in Taiwan
- Bearings ,chain : NTN - Japan
Features :
- Inter-convert automatically levels of speed when stop and start.
- Control system of machine : Stop to cut and holes punching digital length, position and bath ,multi
orders by PLC and Siemens Touch panel (999 programs).
- Signal feedback from encoder showing current length of product and holes position compare with range
- Before finishing each order has alert to pre-cut
- The rollers made of S45C base material solid form CNC precision machined , through hardened with hard
chrome finish get hardness 50HRC.
- Stop hole punching ,pre-cut, profile cut by stationary hydraulic : The cutting and holes punching dies made of SKD 11 base material solid form CNC wire cutting machined , through hardened get hardness 60HRC.
- Emergency stopping system to safe user.
-The machine is equipped with air cooling system allows the machine working continuously from 12 to 16
hours per day.
- A synchronous un coiler speed with roll forming speed
