Help CenterWind Solar Home Hybrid System 600w Wind Turbine Generator
Related Products
Hopeful Wind Energy Technology Co., Ltd. of China specialized in designing and manufacturing small wind turbine,founded in 2003.We focus on manufacturing advanced small wind turbines and related equipments with superior materials. All of the products have passed ISO9001 and Certificate of conformity. We offer VAWT(100w--1000w), HAWT(100w to 300kw) and custom design wind & solar hybrid system.
By now our products have been installed in Europe, America, Mid East and all around the world.
You are welcomed to visit our website to get more information.
Product advantages:
Equipped with famous brand sealed bearing
Waterproofing
Efficient Aero-dynamic design
Unique twin tails, better wind orientation
High strength, corrosion resisting aluminium alloy
Unique neodymium iron boron permanent magnetic material
Low noise level
Main characteristics:
Low start-up wind speed ONLY 3M/S
Wide range of wind speed usability(3.5m/s—25m/s)
Cp value up to 0.43
All-over automatic system
Quality guarantee:
2-year whole system quality guarantee
Highest quality manufacturing standards(ISO9001)
Wide range of temperature tolerance(-20°C—65°C)
High salt fog, dust and sand resistance
Strong wind resistance and high survival wind speed
Durable materials and components
Easy transportation and installation:
Light and compact size
Intuitive online installation guides
Wide installation and maintenance networkworldwide
Perfect after-sales service system
| Technical Specifications | |
| Model | Airforce 1.5L |
| Rated output power | 600 W |
| Max. output power | 750 W |
| Rated Voltage | 12/24 Vdc |
| Rated wind speed | 12 m/s |
| Max. wind speed | 25 m/s |
| Survival wind speed | 60 m/s |
| Start-up wind speed | 3 m/s |
| Cut-in wind speed | 3.5 m/s |
| Rated rotational speed | 810 rpm |
| Max. rotational speed | 920 rpm |
| No. of blades | 3 |
| Rotor diameter | 1.5 m |
| Blade length | 0.68 m |
| Blade material | Nylon & Glass fiber |
| Generator | 3 phases PM generator |
| Braking system | Electromagnetic braking control system |
| Type | Upwind rotor |
| Yaw control | Passive |
| Total weight | 20 kg |
| Warranty | Whole system-2 years |
| Controller | Full-automatic control |
| Tower | 8m(optional) |
Our Product Line
300w ---300kw wind turbine ,On-grid or Off-grid wind & solar & Diesel & Government power hybrid system
Use for Housing use ,public lighting system ,communication base station ,sewage disposal station,toll station and Controller and indicating system ( traffic signal ,road condition signal ,security surveillance and forest fire prevention ) and other project .
OEM service
Q1: Are you factory or trade company ?Where is your factory?
A: We are professional wind turbine factory,specialized in designing and manufacturing wind turbine for 12 years .We are in zhuhai city ,Guangdong province ,near to Macau and Hongkong (15--60mins by ship ).
Q2: Is the wind turbine price listed above include the charge controller and others? If not,where I can purchase the controller and inverter?
A: The listed price is just for wind turbine only (generator + blades), no including controller, inverter and other parts. Please contact our sales for the controller, inverter and other system parts for on grid and off grid application.
Q3: What is the working voltage of your HAWTs for my battery bank or grid utility?
A: Please find our recommended working voltage as below:
300w--12V off-grid
Airforce1.5 600w--12v/24V off-grid
Airforce2.0L/Airforce2.0 ---24v/48v(off-grid )/110V(0n-grid )
Airforce4.1 48V off-grid 220V/380V on-grid
H10kw--30kw 240V on-grid or off-grid
H18-50kw 380V on-grid or off-grid
Q4: What thickness of pole would we use for your horizontal wind turbine and what would be the height approximately of the section that we would add on to your unit?
A: We recommend to use 3mm-5mm thickness, 8m height guyed cable tower or 5mm-8mm thickness, 8-24m height free standing tower or hydraulic tower for our HAWT 1KW-50KW. Please contact our sales to get more tower information.
Q5: How is your HAWTs to realize the security protection during heavy winds?
A: There are multi security protection to ensure our HAWTs speed regulation and protection during high wind: yawing + electromagnetic brake (by controller) + manual brake (available on HAWT 5KW to 30KW models).
Any interests and questions, please send us inquiry or call us.
Website:
Skype:sales05_hopeful QQ: 568386513
Office number :+86 756 3819 866 to Steve Li
