200w Mini Wind Turbine Vertical Axis Wind Turbine Generators

Name: 200w Mini Wind Turbine Vertical Axis Wind Turbine Generators
Brand: Hopeful
Availability: InStock

FOB Price

US$ 325 - 340 / Unit

1 Unit(Min. Order)

Port Zhuhai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Hopeful
Model Number	V1s		Type	Wind Power Generator

Product Description

About us

Hopeful Wind Energy Technology Co., Ltd is a company specialized in designing and manufacturing small wind turbines from the year of 2003. We focus on manufacturing advanced small wind turbines and related equipments with superior materials. Our products are designed to operate in harsh working environments, extreme conditions and generate power to the utmost. In order to achieve this goal, we will strive to find some feasible solutions to improve our technology and services continuously. Hopeful is not only trying to sale products, but also to propose a lifestyle. We are always trying to give our customers a tailor-made option for their needs. So far, we have created schemes such as Wind/Solar / Diesel Hybrid Microgrid System, Wind / Solar Hybrid System and Wind / Solar Hybrid Street Lamp System. As the executive member of CWEEA, Hopeful's products passed the Certification of Europe and ISO9001 quality management system certification. We obtained two Appearance Design Patents and eight Utility Late-models. At present, our products are mainly exported to countries in Asia, Europe, America and so on.Since alternative energy can reduce carbon emission and improve our living environment, Hopeful Energy's team are making every effort to study, develop, manufacture and sell many kinds of wind power products and their supporting systems, and provide good after-sales services to the worldwide end users.

Product Description

Product advantages:

1.Disk generator, without iron core, low starting torque

2.S type design ,attractive design

3.High strength, corrosion resisting aluminum alloy

4.Low noise level

5.High-performance neodymium iron boron permanent magnetic material

6.High moisture , salt fog, dust and sand resistance

7.Superior SKF bearing

Product performance :

1.Low star-up wind speed ONLY 1.5 m/s

2.No restriction to the wind direction

3.Wide range of wind speed usability (1.5m/s-25m/s)

4.Cp value up to 0.4

5.All-over automatic control system

Quality guarantee:

1.Two-year limited guarantee

2.ISO9001 quality management system

3.Operation temperature: -30℃-65℃

4.High standard test of corrosion and sand resistance

Easy transportation and installation:

1.Light and compact size

2.Intuitive online installation guides

3.Wide installation and maintenance network worldwide

4.Perfect after-sales service system

Technical specifications :

Model	V1s
Rated output power	200w
Max. output power	250w
Rated Voltage	14.5Vac
Rated wind speed	12m/s
Survival wind speed	65 m/s
Start-up wind speed	1.5m/s
Cut-in wind speed	4 m/s
Rated rotational speed	250rpm
Max. rotational speed	300 rpm
No. of blades	1
Rotor diameter	0.9 m
Blade length	1m
Blade material	FRP
Generator	Disk generator
Total weight	25kg
Warranty	Whole system-2 years
Tower	8 m (optional)

Certifications

Packaging & Shipping

Our Services

Our Product Line

200w ---300kw wind turbine ,On-grid or Off-grid wind & solar & Diesel & Government power hybrid system

Use for Housing use ,public lighting system ,communication base station ,sewage disposal station,toll station and Controller and indicating system ( traffic signal ,road condition signal ,security surveillance and forest fire prevention ) and other project .
