LED Touch Display

Name: LED Touch Display
Brand: Hitouch
SKU: 124960435
Availability: InStock

US$ 1,265 - 5,620 MOQ: 10 Pieces

Key Specifications

Products Status:

Stock

Screen Size:

Other, 42"

Type:

Other, Surface Light Wave

Hongkong Vaborn Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Screen Size Other, 42"

Type Other, Surface Light Wave

Interface Type USB

Resolution 1024 x 768

Brand Name Hitouch

Model Number HT-SLWTM42M2

Place of Origin Guangdong, China

Specifications

LED touch display
1.LED multitouch monitor display
2.finger touch LED monitor
3.Dual touch display

LED touch display

1.LED multitouch monitor display

2.finger touch LED monitor

3.Multi touch under win7

4.2/6/10/16/32points

Application:

Interactive advertising & teaching

Infrared Touch Screen Specification

Function Spec
Touch Accuracy	±1mm, over 90% in sensitive touch area, resolution reported by USB is: 32767*32767
Response Speed	≤6ms
Touch Object	Finger, glove hand, or other opaque object
Touch time	No limited
Sampling rate	60ppi/s
Touch pressure	No
Min touch object	3mm*3mm
Surface durability	Hardness of glass is level 7

Luminousness

≥92%,can up to 100%(no glass)

Electronic Spec
Power Supply	USB, 300mA, Max 500mA
Anti-Static	EN 6100-4-2 1995: Level 4, Non-contact discharge 8 kV, Air discharge 15 kV
Interface	USB2.0(Full speed)

LED Specification

Product Size	42inch & 55inch & 65inch
Active Size	42” 531.26939 mm/ 55” 688.41217.6mm/ 65” 814.6*1440.6mm
Display Type	LED
Screen proportion	16:9
Contrast	6000:1
Brightness	450 CD/m^2
Color	1677pixels
Resolution	1920×1080
TV Mode	PAL BG/DK/I;SECAM BG/DK
Computer compatibility	VGA/SVGA/XGA/SXGA
Input Port	2 AV/Audio,1 S-Video/ Audio,1 VGA/ Audio,2 YpbPr/YcbCr,1 TV,2 HDMI
Output Port	None
SIF Output	L,R:2X8W
Viewing Angle (top/bottom/left/right)	88/88/88/88
Life time	Around 40000 hours
Power Requirement	AC(100~240)V
Power Management	Stand-by:1W ;work:≤460W
Operation Environment	Work Temperature:5°C~ 40°C Work Humility:≤80%
Operation Environment	Store Temperature:-20°C—40°C Store Humility:≤80%
Computer Response	Auto-Detect
