4GE+2FXS EPON ONT Fiber Optical VoIP Home Gateway

Name: 4GE+2FXS EPON ONT Fiber Optical VoIP Home Gateway
Brand: V-Solution
SKU: 124917337
Availability: InStock

Guangzhou V-Solution Telecommunication Technology Co., Ltd.

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

V-Solution

Model Number:

HG324E

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name V-Solution

Model Number HG324E

Parameter Name	Hardware Parameter
	EPON	GPON
Chipset	BCM68380 Series
PON	SC single-mode/single-fiber, symmetric 1.25Gbps	SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength	Tx 1310nm, Rx 1490nm
Sensitivity	<-27dBm(PX20+)	<-27dBm(CLASS B+)
Optical Type	SC/PC
Interface Type	4*10/100/1000Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connector 2 POTS, RJ11 connector
Indicators	9, For POWER,PON ,LOS,WAN,Lan,Phone

Parameter Name	Software Parameter
	EPON	GPON
LAN	Support Port rate limiting Support Loop detection
VLAN	Support VLAN tag mode Support VLAN transparent mode Support VLAN trunk mode Support VLAN translation mode Support VLAN QinQ mode
Multicast	Support IGMPv1/v2/v3 Support IGMP Proxy and MLD Proxy Support IGMP Snooping and MLD Snooping
QoS	Support 4 queues Support SP and WRR Support 802.1P Support DSCP
L3	Support IPv4,IPv6 and IPv4/IPv6 dual stack Support DHCP/PPPOE/Statics Support Static route Support NAT Support Bridge, Route ,Route and Bridge mixed mode Support DMZ Support DNS Support ALG Support UPnP Support Virtual Server
DHCP	Support DHCP Server
VOIP	Support SIP protocol Support Voice coding: ITU-T G.711/G.723/G.726/G.729, auto-negotiate with call agent Support Echo cancellation exceeding ITU-T G.165/G.168-2002, up to 128ms tail length Support high/low speed fax/Modem, bypass fax, and T38 fax Support InBand / RFC2833/SIP INFO, MD5 authentication, call forward, call waiting, hot-line call, and all kinds of value-added voice service. Multi-party conferencing Support Line testing according to GR-909
Performance	Data loss: <1*10E-12 Call loss: <0.01%
Security	Support Firewall Support Mac filter Support ACL Support URL filter
Management	Support CTC OAM 2.0 and 2.1	Support OMCI(ITU-T G.984.x)
	Support WEB Support TR069 Support TELNET Support CLI
