PP melt-blown filter cartridge
Features:
- Made of PP, its tubular filter materials is sintered by continuous PP long fiber through melt-blown process.
- High filtering precision, large flowage, even structure, strong waste load capacity, long service life.
- Good chemical compatiblity, no any additives, not easilly fall-off fiber.
- Wide application, strong waste rejection capacity.
Technical parameters list
| Precision | 0.5 1 3 5 10 20 25 30 50 75 100 | ||
| Length | 5” 10” 20” 30” 40” | Working temperature | <60°c |
| Diameter | 65mm |
Maximum temperature resistance | <90°c |
| Filtering materials | PP | Max inlet pressure | 5.2bar(25°c) |
| Support materials | PP(optional) | 2.6bar(25°c) | |
| Materials of case | PP(optional) | Recommended changeover pressure difference | 1 bar |
| Filtering area | 0.05m²/10” | Max pressure difference | 3.5bar(25°c) |
Application
Security filtration before reverse osmosis
Sewage treatment
Filtration for high pure water
Prefiltration or terminal filtration for other chemicals
Materials of Construction | |
Membrane |
Hydrophilic MCE |
Support |
PP |
Core, Cage and Drainage |
PP |
End Caps |
PP (222/226 with encapsulated stainless steel reinforcing ring) |
O-rings/Gasket |
Silicone/EPDM/Viton/TEV |
Sealing Technology |
Thermal Bonding, No Adhesives |
Dimensions | |
Diameter |
Φ68 |
Length |
5 inch, 10 inch, 20 inch, 30 inch, 40 inch |
Filtration Area, ft 2 | |
≥ 6.4 per 10-inch element | |
Pore Size, μm | |
0.1, 0.22, 0.45, 0.65, 1.0, 3.0, 5.0 | |
Maximum Differential Pressure | |
Forward: 4.2 bar @ 23 ºC ; 1.5 bar @ 85 ºC | |
Flow Rate & Pressure Drop , per 10-inch cartridge | |
0.1 μm |
≥ 10 L/min at 210 mbar |
0.22 μm |
≥ 17 L/min at 210 mbar |
0.45 μm |
≥ 30 L/min at 210 mbar |
Particle Removal Efficiency (%) | |
>98 | |
Good Manufacturing Practices | |
Manufactured in an ANOW facility which adheres to Good Manufacturing Practices. | |
High-Tech and Science results certificates
Iso 9001 international quality certificate
Patents (we have 20 patents which are authorized by STATE INTELLECTUAL PROPERTY OFFICE OF THE P.R.C)
Exhibition
