Specifications
Semi-automatic PE L Sealing Machine1.Manual or pneumatic sealer
2.CE
3.Economic L grade Sealer
4.Conveyor speed adjustable
Established in 2004, Nanjing Jinhuigu Industrial Trade Co., Ltd. is a specialized supplier of packing materials, packing machinery, plastic processing equipment and other materials.
Specifically, our main products include polyolefin/PVC shrink film, PVC cling film, PE stretch film, and other packing material. Moreover, we are also cooperated with qualified manufacturers to making plastic processing equipment according to the requirement of clients, such as triple bubble line for producing barrier shrink film, slitter and folder, and special wrapping shrink equipment.
Since the establishment, we have been devoting ourselves to developing various sources according to the requirement of our clients. We are not only importing and exporting various products as an authorized agent from manufacturers, but also a representative of some North American and European companies in China. We have obtained good reputation and built excellent relationships with various manufacturers both domestic and overseas. Presently, we are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more details.
View of workshop
View of half-finished products
view of factory
1."L" Grade Film sealing machine;
2.Cutting and sealing system consists of Alchrome Alloy Wire with constant-heat,no-smoke,stick-free function;
3.Sealing frame integrates with excellent protection device;
4.Wrapped product will feed into shrinking tunnel automatically by Conveyor belt which was adjustable in speed;
5.The height of conveyor platform adjustable;
6.Manual or automatic pneumatic sealing system;
7.Easy to maintain;
9.Pneumatic sealing system(lb-601a) contains automatic sealing cycle function.
Model |
LB-601 |
LB-601A(Pneumatic) |
LB-602 |
LB-603 |
||
|
Machine Size(mm) L x W x H |
1765x810x975 |
1615x740x1070 |
2410x1095x1515 |
2840x1565x1310 |
||
|
Packing Size(mm) L x W x H |
(10-500)x(100-400)x(2-280) |
(10-850)x(10-650)x(2-280) |
(200-1150)x(200-870)x(5-280) |
|||
|
Sealing bar (mm) L x W |
530x450 |
900x700 |
1300x900 |
|||
Power |
1p,220v,4kw |
1p,220v,7kw |
1p,220v,9kw |
|||
|
Packing Capacity |
8-10 packs/min |
|||||
Pneumatic |
N/A |
55psi,4kg/sq.cm |
N/A |
N/A |
||
*Tailor made version is available
TS-450-1500
T-850-200
