Specifications
Automatic Vertical PE L Sealing Machine1.Adjustable Sealing seam;
2.Automacit Film advance system;
3.Film scrap receiver;
Established in 2004, Nanjing Jinhuigu Industrial Trade Co., Ltd. is a specialized supplier of packing materials, packing machinery, plastic processing equipment and other materials.
Specifically, our main products include polyolefin/PVC shrink film, PVC cling film, PE stretch film, and other packing material. Moreover, we are also cooperated with qualified manufacturers to making plastic processing equipment according to the requirement of clients, such as triple bubble line for producing barrier shrink film, slitter and folder, and special wrapping shrink equipment.
Since the establishment, we have been devoting ourselves to developing various sources according to the requirement of our clients. We are not only importing and exporting various products as an authorized agent from manufacturers, but also a representative of some North American and European companies in China. We have obtained good reputation and built excellent relationships with various manufacturers both domestic and overseas.
Presently, we are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more details.
VIEW OF WORKSHOP
VIEW OF HALF-FINISHED SEALING MACHINE
VIEW OF FACTORY
LB-801 AUTOMATIC VERTICAL PE L SEALING MACHINE
1.The sealing system capable of produce smooth and firm sealing line.The sealing blade was with safety protection and alarm device, anti-adhesive,no smoke,constant temperature ;
2.4 pillars drive sealing frame to reduce folding on sealing seam.Sealing frame is adjustable, sealing seam can adjust by product height.
3.The procedure of packing from feeding, sealing, to shrinking is operated automatically;
4.The automatic L sealing machine is available for various kinds of films as PE ,POF PVC ;
5.Broad application, a universal selection for various products;
6.Two sets of photoelectric sensor system for precise package length;
7.Energy saving and shorten the working hours
8.Automatic film scrap receiver.Automatic film advance system;
9.Equipped with easy adjust perforation system and transparent hood.
10.Smallest version LB801 is designed for packing very thin and fine products.
Model |
LB-801 |
LB-802 |
LB-803 |
|
|
Machine Size(mm) L x W x H |
1475x1320x1230 |
2000x1450x1315 |
2420x1710x1325 |
|
|
Packing Size(mm) L x W x H |
(50-400)x(50-280)x(2-80) |
(60-560)x(60-430)x(10-180) |
(200-830)x(200-630)x(10-180) |
|
|
Sealing bar (mm) L x W |
450x335 |
630x515 |
900x700 |
|
Power |
1p,220v,2.5kw |
1p,220v,3kw |
1p,220v,4kw |
|
|
Conveyor Speed |
26 m/min |
|||
Pneumatic |
55psi,4kg/sq.cm |
55psi,4kg/sq.cm |
87psi,6kg/sq.cm |
|
*Tailor made version is available
TS-450-1500
T-850-200
