Help CenterWaterproof Electric Y Type Multi Connector With PVC or Nylon
Related Products
-
IP68 Y Type Multi Split Core Waterproof Connector WireUS$ 0.1 - 5MOQ: 1000 Pieces -
New Design Thru Board Inverted 2-pin Mini Smt Terminal Block for Led Bulb LightsUS$ 0.2 - 5MOQ: 1000 Pieces
-
0809 Screw On Wire ConnectorUS$ 0.2 - 5MOQ: 1000 Pieces
-
UL VDE Style No.3239, 3135 Silicone Rubber WireUS$ 0.05 - 5MOQ: 1000 Meters
-
Male and Female ConnectorUS$ 0.6 - 5MOQ: 1000 Pieces
Y type multi specifications:
1,Operating temperature: -25 ℃ ~ 85 ℃
Storage temperature: -25 ℃ ~ 85 ℃
Atmospheric pressure: (86 ~ 106)
KPa waterproof grade: IP65
2: Structure description
Shape size (length * width * height) (mm): see drawings.
Pinout: Skinning dipping tin
contact plastic material: PVC.
3: Test
In accordance with the GJB1217-1991 1005 method, under normal temperature and pressure, conductors and insulators, the test voltage (effective Value) AC 1500V / 50Hz, 1min and no breakdown or arcing phenomenon, super leakage current of less than 2mA.
In accordance with the GJB1217-1991 1005 method, under normal temperature and pressure, conductors and insulators, the test voltage (effective value) of DC 500V, insulation resistance is greater than 1000M.
Connector is not inserted in accordance with the provisions of GJB1217-1991 1001, connector to withstand salt solution concentration of 5% Sodium chloride solution, 48h neutral salt spray test temperature 35 ± 2 ℃, does not appear to affect the performance of corrosion.
4: Core wire: 2x.0.75mm2
Core wire covering material: rubber.
Wire color: Brown and blue.
5: Y type multi split core waterproof connector wire specifications:
1)Y type one to two core waterproof connector wire:
Into wire core number: one, out wire core number: two, rated current: 15A, rated voltage: 500V, insulation resistance: >2000M Ω, housing material: PVC/ nylon;
2)Y type one to three three core waterproof connector wire:
Into wire core number: one, out wire core number: three, rated current:10A, rated voltage: 500V, insulation resistance: >2000M Ω, hosing material: PVC/ nylon;
3)Y type one to four core waterproof connector wire:
Into wire core number: one, out wire core number: four,rated current:5A, rated voltage: 500V, insulation resistance: >2000M Ω, case material: PVC/ nylon;
4)Y type one to five core waterproof connector wire:
Into wire core number: one, out wire core number: five, rated current:3A, rated voltage: 500V, insulation resistance: >2000M Ω, case material: PVC/ nylon;
5)Y type two to three core waterproof connector wire:
Into wire core number: two, out wire core number: three, rated current:10A, rated voltage: 500V, insulation resistance: >2000M Ω, case material: PVC/ nylon;
6)Y type two to four core waterproof connector wire:
Into wire core number: two, wire core number: four, rated current: 5A, rated voltage: 500V, insulation resistance: >2000M Ω, case material: PVC/ nylon;
7)Y type two to five core waterproof connector wire:
Into wire core number: two, wire core number: five, rated current:3A, rated voltage: 500V, insulation resistance: >2000M Ω, case material: PVC/ nylon
We cooperated with local fedex, dhl, ups, tnt,ems, and got more than 50% discount, help you save the shipping cost, and let you receive it in 3 to 10 days.
1 Reply your enquiry in 24 working hours.
2 Experienced staffs answer all your questions in fluent English
3 Customized design is available .
4 Unique solution can be provided to our customer by our well-trained and professional and staffs
Why Trust Us:
1. Sineyi CO.,LTD is a professional manufacturer and exporter of cable glands, cable connector,etc wiring accessories. We have advanced production equipment, abundant technical force.
2. Sineyi quality is first in China(Mainland). Our quality of cable gland is same as AVC Corp( Tainwan).
3. Sineyi engineer team have at least 15 years experience to develop new mold every month.
4.Sineyi size and type of cable gland is most complete in China to satisfy different cable range.
5. Sineyi develop new products every year to keep the competitiveness in the market
6.Above payment: D/A D/P T/T L/C Western Union MoneyGram Paypal
