Home > Consumer Electronics > LED Display > Indoor LED Display > High Quality Low Price P12.5 Indoor Full Color Transparent Led Display Screen
High Quality Low Price P12.5 Indoor Full Color Transparent Led Display Screen
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Proge transparent led display screen
Model Number:
PG-OSC-P12.5
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lightweight Low Price P12.5 Indoor Full Color Led Mesh ScreenNegotiableMOQ: 1 Square Meter -
1000x500mm P10.42 Outdoor Full Color hd Flexible Led CurtainUS$ 1,000 - 3,000MOQ: 1 Square Meter
-
P6.25 Indoor Full Color Stage Background Decoration Led CurtainUS$ 1,000 - 3,000MOQ: 1 Square Meter
-
P6.25 Indoor Full Color Smd 3528 Soft Led Video CurtainUS$ 1,000 - 3,000MOQ: 1 Square Meter
-
P6.25 Smd 3535 Full Color Flexible Outdoor Led CurtainUS$ 1,000 - 3,000MOQ: 1 Square Meter
Place of Origin
China
Brand Name
Proge transparent led display screen
Model Number
PG-OSC-P12.5
Usage
Outdoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
Other, 12.5mm
Screen Dimension
transparent led display screen
high quality low price p12.5 indoor full color transparent led display screen
Features:
*Weatherproof to IP65 standards
*High resolution images
*Easily configured for various size and aspect ratios
*Wide viewing angle
*Compatible with inputs: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA
Main Application: Stage and outdoor fixed installation
Specification:
| Parameter | Unit | Value |
| Pitch | mm | 12.5 |
| Brightness | nits | 6,000 |
| Color temperature | deg. K | 6,500 |
| Viewing angle – Horizontal (50% brightness) | deg. | 120(-60~ +60) |
| Viewing angle – Vertical (50% brightness) | deg. | 120(-60~ +60) |
| Cabinet weight | kg | 6 |
| Cabinet width | mm | 800 |
| Cabinet height | mm | 600 |
| Cabinet depth | mm | 65 |
| Cabinet area | sq. m. | 0.48 |
| Cabinet material | Epoxy paint coated Aluminum Strip | |
| Transparent Rate | 25% | |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| International Protection | IP | IP65/43 |
| Pixel type and configuration | R/G/B | 3in1 SMD |
| Resolution per panel | 40x40 | |
| Dot per panel | 1,600 | |
| Dot per sq. meter | 6,400 | |
| LED per sq. meter | 6,400 | |
| Recommended minimum viewing distance | m | 9.5 |
| Drive Mode | Constant current drive Static | |
| Colors | 281 Trillion | |
| Grey scale (linear) | Levels | 65,536 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio | 1,000:1 | |
| Processing depth | bit | 16 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3,000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts/ panel | 200 |
| Input power (typical) | Watts/ panel | 140 |
| Lifetime (50% brightness) | Hours | ≥100,000 |
| Red wavelength (dominant) | nm | 620~625 |
| Green wavelength (dominant) | nm | 525~530 |
| Blue wavelength (dominant) | nm | 470~475 |
| Multimedia data format | DVI,MPG,AVI,WMV,RM etc. | |
| Mounting System | Hanging/Fix Installation |
high quality low price p12.5 indoor full color transparent led display screen
