stage portable p5 smd indoor rgb led pannel

FOB Price

USD $1,000 - $3,000 / Square Meter

1 Square Meter(Min.Order)

Supply Ability 5000 Square Meter / Square Meters per Month
Port Shenzhen
Payment Terms:Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	China	Brand Name:	Proge indoor rgb led pannel	Model Number:	PG-IFC-P5
Usage:	Indoor	Tube Chip Color:	Full Color	Display Function:	Video
Pixels:	Other, 5mm	Screen Dimension:	indoor rgb led pannel

Product Description

stage portable p5 smd indoor rgb led pannel

Features:

1) Price Advantage: We have the best competitive price at the market, also have the same even better quality.
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!

Specification:

Indoor full color led display screen technical parameter
Items	P5 full color indoor led display
Pitch size	5mm
Module size	320mm*160mm
Module pixel(dots)	64dots*32dots
Pixel configuration	1Red, 1Green, 1Blue
LED chip	Silan
Color scale	65536degree/16777216colors
Pixel density	40000pixels/square meter
View angle(H/V)	≥ 120/120degree
Brightness	≥ 800cd/square meter
Brightness adjustment	64 level automatic or manual
View distance	3--100m
Power consumption	100-1600W/square meter
Net weight	less than 45kg/square meter
Operating temperature	_ 25° C~+60° C
Operating humidity	10%_ 95%RH
Life time	≥ 100, 000hours
Out of control dot	≤ 1/10, 000
Whole Display Flatness	≤ 1mm Juncture
Exchange frame speed	> 150frames per second
Refresh frame frequency	600Hz
Control distance	120m (without repeater), single mode fiber: 20km, multi mode fiber: 500m
Power	110V/220V± 15% 50Hz
Operating system	Windows98/Me/2000/Xp
Drive mode	constant current driving, 1/8 scan
Display mode	VGA640X480_ VGA1600X1024
Protections for outdoor display	IP54
Maintenance way	Rear access
Accepting signal	PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite Video; SDI
