Specifications
laser cnc metal cutting machinery1.IPG/Coherent fiber
2.Power 300w 500w 1kw 2kw
3.Fixed knife trip
4.Low cost
Fiber laser source is the most advanced laser source for metal cutting, there is a lot of unique advantages, such as free maintenance, lowest power consumption and longest working lifespan and the most important is highest accuracy and effiency during processing the metal materials. For the laser source ,we import from the most famous company IPG to ensure our machines good quality.
| Fiber Laser Cutting Advantage |
(1) The fiber laser series are Golden Laser’s new line of metal precise processing equipment powered by fiber laser technology. The quality fiber laser beam results in faster cutting speeds and higher quality cuts compared to other cutting solutions. The key advantage of a fiber laser is its short beam wavelength (1,064nm). The wavelength, which is ten times lower than that of a conventional C02 laser, generates high absorption into metals. This makes the fiber laser become a perfect tool for cutting sheets of stainless steel, mild steel, aluminum, brass, etc.
(2)The efficiency of a fiber laser far exceeds traditional YAG or CO2 laser equipment. The fiber laser beam is capable of cutting reflective metals with much less energy as the laser is absorbed into the metal being cut. The unit will consume little to no energy when not active.
(3) Another advantage of fiber laser is the use of highly reliable single emitter diodes with projected lifetimes greater than 100,000 hours of continuous or pulsed operation.
(4) Golden Laser software allows for the capability to control power, modulation rate, pulse width and pulse shape giving the user full control of the lasers capabilities. |
||||||||||||||||||||||||||||||||||||||||||
| Golden Laser - Metal Laser Cuttig Machine | |
||||||||||||||||||||||||||||||||||||||||||
| Advantages Comparison between Different Types of Laser Generators |
|
||||||||||||||||||||||||||||||||||||||||||
| Fiber Series-Recommend Model XJG-150300DTB |
|
||||||||||||||||||||||||||||||||||||||||||
| XJG-150300DTB Fiber Laser Cutting Machine Features |
1>The double ball screw closed-loop system and imported open CNC system ensure high processing accuracy, high working efficiency and high speed.
2>Standard collocation of 500W fiber laser generator and optional 300W~2000W fiber laser generator. Low operation and maintenance cost and maximum long-term investment returns and profits.
3>Enclosure design meets CE standard, reliable and safe processing. Shuttle table/pallet working tables convenient for material uploading and unloading and further promotes working efficiency.
4>Aiming at high speed cutting, we design and manufacture strengthened welded machine body after 2 times of aging process which ensures long-term accuracy and stability of performance.
5>Standard collocation of dual-pressure gas control system of 3 gas sources (high pressure air, nitrogen, oxygen) meets the processing requirement of all kinds of materials. Easy operation and low cost.
6>Standard collocation of automatic nesting software (including material management and optimized processing technology) and database of process parameters is provided for easy operation and simple management.
7>Optimized optical lens, specially designed nozzle and sensor technology realize more smooth and more stable cutting. |
||||||||||||||||||||||||||||||||||||||||||
Fiber Laser Cutting Live-Action: |
|
||||||||||||||||||||||||||||||||||||||||||
|
YAG Fiber Laser Cutting Live-Action: |
|
||||||||||||||||||||||||||||||||||||||||||
| XJG-150300DTB Application |
Fiber Laser Cutting Machine Applicable Materials: Laser cutting stainless steel, mild steel, carbon steel, alloy steel, spring steel, iron, galvanized iron, galvanized sheet, aluminum, copper, brass, bronze, gold, silver, titanium plates, metal sheets, metal plates, metal tubes and pipes. Cut the shape of Circle, Triangle, Octagonal and so on
Fiber Laser Cutting Machine Applicable Industries: laser cutting machines have been widely used in manufacture billboard, advertising, signs, signage, metal letters, LED letters, advertising letters, sheet metal processing, metals components and parts, ironware, chassis, racks & cabinets processing, kitchen ware, metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, jewelry, glasses frame, nameplates, electronic parts, etc. |
||||||||||||||||||||||||||||||||||||||||||
| Main Technical Data |
|
||||||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
| Laser Cutting Metal,Samples Gallary | |
||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
|
Get Your Hand; Move your Mouse Ready go for Laser Metal Cutting Machine |
|||||||||||||||||||||||||||||||||||||||||||
| GoldenLaser-Overviews |
|
||||||||||||||||||||||||||||||||||||||||||
| Contact Information | Attn: Ms Kelly Li |
||||||||||||||||||||||||||||||||||||||||||
| Notice |
When inquiry for price list,working videos,package,delivery time and more specification,please let me know : 4,What is your full name,email,company name,website,mobile number? |
||||||||||||||||||||||||||||||||||||||||||
