Best Price LTMA Forklift for Sale in Dubai

Best Price LTMA Forklift for Sale in Dubai thumbnail-1
Best Price LTMA Forklift for Sale in Dubai photo-1
US$ 8,000 - 25,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Fujian, China
Brand Name:
LTMA
Contact Supplier Request Quote Chat Now
Xiamen Xinlongteng Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Fujian, China
Brand Name LTMA
Model Number FD30T
Type Powered Pallet Truck
Power Souce Diesel Engine
Rated Loading Capacity 3T
Max. Lifting Height 3M-6M
Fork Length 1070
Fork Width 125
Overall Dimensions 1220*150*60
Certification ISO/ CE
After-sales Service Provided Overseas third-party support available



Product Description



LTMA 1.5 ton to 5 ton diesel forklift for sale in dubai

best price LTMA forklift for sale in dubaibest price LTMA forklift for sale in dubai

best price LTMA forklift for sale in dubai

best price LTMA forklift for sale in dubaibest price LTMA forklift for sale in dubai

best price LTMA forklift for sale in dubai

2 ton 3 ton forklift made in China



Features
1 Manufacturer                              LTMA LTMA
2 Model                                      Power shift T/M     FG30T FG35T FD30T FD35T
Manual shift T/M      FG30C FG35C FD30C FD35C
3 Load capacity                       kg 3000 3500 3000 3500
4 Load center    mm 500 500
5 Power unit      Gasoline Diesel
6 Operator type      Driver/seat  Driver/seat
7 Tire type  Front/rear   Pnenumatic  Pnenumatic
8 Wheel  Front/rear   2/2 22
Dimension  9 Max. lifting height                   mm 3000 3000
10 Free lift                           mm 150 150
11 Fork size              L*W*T mm 1070*125*45 1070*125*50 1070*125*45 1070*125*50
12 Tilt range                           Mast forward/backward          deg 6/12 6/12
13 Overall length(without fork)      mm 2660 2720 2660 2720
14 Total width    mm 1225 1285 1225 1285
15 Mast height (fork lowering)    mm 2075 2075
16 Overall height fork raised     With backrest                         mm 4250 4250
17 Height to head guard             mm 2140 2140
18 Turning raduis(outside)        mm 2400 2460 2400 2460
19 Front face of fork to front axle   mm 480 485 480 485
20 Min. right angle stacking aisle without load length&clearence                     mm 2880 2940 2880 2940
Performance  21 Speed  Max Travelling         full/no load km/h 18/19.5 18/19.5
22 Lifting             full/no load       mm/s 450/500 450/500 450/500 450/500
23 Lowering         full/no load                mm/s 450/450 450/420 450/450 450/420
24 Max.drawbar pull               Power shift T/M     full/no load                                     kg 1300/1000 1800/1000 1500/1000 2200/1000
Manual shift T/M       full/no load                                    kg 1350/1000 1900/1000 1550/1000 2200/1000
25 Gradeability at 1.6km/h         Power shift T/M     full/no load                                      % 17/20 17/20 18/20 18/20
Manual shift T/M       full/no load                                    % 17/20 17/20 18/20 18/20
Weight
26 Truck weight    kg 4220 4610 4290 4690
27 Weight distribution             Full load             front/rear     kg 6390/830 7260/850 6420/870 7300/890
28 No load               front/rear       kg 1650/2570 1840/2770 1680/2610 1880/2810
Frame
29 Tires                                        Number  front/rear 2/2 2/2
30 Model  front axle 28x9-15-12PR 28x9-15-12PR
31 rear axle  6.50-10-10PR 6.50-10-10PR
32 Wheelbase    mm 1700 1700
33 Tread                                        Front/rear mm 1000/970 1060/970 1000/970 1060/970
34 Ground clearence        At lowest point(mast)                 mm 120 120
Frame  mm 135 135
35 Brake                                            Service brake   Hydraulic-foot peda                                Hydraulic-foot peda
Parking brake    Mechanical-hand lever                                         Mechanical-hand lever
Engine
36 Battery                                          Voltage/capacity V/AH 12/60 12/80
37 Engine                                          Model   Nissan K21 Nissan K25 ISUZU C240 ISUZU 4JG2
Rated power  PS(kw/rpm) 47/2250(34.6/2250) 51/2300(37.4/2300) 52/2500(38.3/2500) 61/2450(44.8/2450)
Rated torque  kg-m   max.(N.m) 15.7/1600(153/1600) 18/1600(177/1600) 15.7/1800(154/1600) 19/1800(186/1800)
Number of cylinders    4 4 4 4
Placement  L 2.065 2.488 2.369 3.059
Fuel tank capacity  L 70 70
38 Transmission                              Speed forward/backward           Power shift T/M        Manual shift T/M       1-1 power shift T/M                                                                         2-2 power shift T/M                                         1-1 power shift T/M                                                                                 2-2 power shift T/M
39 Operating pressure                    Hydraulic system pressure            kg/cm² 180 180

 best price LTMA forklift for sale in dubaibest price LTMA forklift for sale in dubai

Packaging & Shipping



 best price LTMA forklift for sale in dubaibest price LTMA forklift for sale in dubai

Company Information

 best price LTMA forklift for sale in dubaibest price LTMA forklift for sale in dubai





Our Services

 After-sale service

LTMA always treat after-sale service more important than sale. Nowadays more than 10 agents around the world can supply LTMA professional after-sale service.

All the product of LTMA supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Detail clauses and policies please check our website and product certificate.



FAQ



1.What's the Certificate do you have?

LTMA workshop meet with the ISO9001:2008 Quality System. All of our products with CE certificate.  Some of our products meets the EPA requirements.  LTMA never recruit Underage labor.



2. Can you customize and design as the clients' requirement?

LTMA will try its best to meet all kinds of clients' special requirements. However, All the customizing and refit should be implemented safely and scientifically.

The colors can be painted as client's need.



3.How long is the warranty of your products?

Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMA warranty policy for each model.



4. Can you produce the products labeled with the client's brand?

With the authorization of the brand, we can OEM for our clients.



5. What's the payment terms do you accept?

Normally 30% T/T in advance as deposit, blance paid before shipment.

100% L/C at sight issued by world famous bank with good faith is also available.



6.Delivery time:

Standard configuration products are always in stock. The production period of Customizing products is from 7 days to 90 days.



7, How can you ensure the quality of the products ?

Don’t worry,we joined the trade assurance. If the products have quality problem when you received the goods, Alibaba can return you full payments.
