LTMA New Arrival FB20 Small Battery Charger Operated Forklift

LTMA New Arrival FB20 Small Battery Charger Operated Forklift thumbnail-1
LTMA New Arrival FB20 Small Battery Charger Operated Forklift photo-1
US$ 12,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Fujian, China
Brand Name:
LTMA
Contact Supplier Request Quote Chat Now
Xiamen Xinlongteng Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Fujian, China
Brand Name LTMA
Model Number FB20
Type Powered Pallet Truck
Power Souce DC Motor
Rated Loading Capacity 2000kg
Max. Lifting Height 3M-6M
Fork Length 1070
Fork Width 122
Overall Dimensions 2245*1150*1995
Certification CE/ISO
After-sales Service Provided Overseas third-party support available



Product Description

LTMA New arrival FB20 small battery charger operated forklift



Technical secification of battery forklift
Features     1 Manufacturer                          LTMA
2 Model                                       FB20
3 Load capacity                           kg 2000
4 Load center                              mm 500
5 Power unit                               Battery ,diesel ,gasoline  Battery
6 Operator type                             Driver/seat
7 Tire type                              Front/rear   Air tires
8 Wheel                                     Number      Front/rear 2X/2
Dimension   9 Max. lifting height                      mm 3000
10 Free lift                                    mm 160
11 Fork size                                                     L*W*T mm 1070*122*40
12 Tilt range                                 Mast forward/backward        deg 6-12
13 Overall length(without fork)       mm 2245
14 Total width                                mm 1150
15 Mast height (fork lowering)      mm 1995
16 Overall height fork raised        With backrest                mm 4030
17 Height to head guard                 mm 2145
18 Turning raduis(outside)             mm 1980
19 Front face of fork to front axle   mm 445
20 Min. right angle stacking aisle not add load length&clearence              mm 1885
Performance   21 Speed  Max Travelling         full/no load km/h 13.5/15
22 Lifting              full load             mm/s 240
23 Lifting             no load               mm/s 450
25 Gradeability                                     full load    % 12.5
Weight             26 Truck weight                            kg 3440
27 Weight  distribution             Full  load              front/rear      kg 4565/875
28 No  load               front/rear   kg 1445/1995
Frame            29 Tires                                        Number  front/rear 2/2
30 Model  front axle   21x8-9-16PR
31 rear axle  18x7-8-14PR
32 Wheelbase                                 mm 1400
33 Tread                                                Front/rear mm 955/950
34 Ground clearence                   At lowest point(mast)               mm 110
Frame  mm 115
35 Brake                                             Service  brake   Hydraulic-foot peda
Parking brake   Mechanical lever
Electric motor and controller
36 Battery  Voltage/capacity V/AH/5hr 48V-450
37 Weight (standard) kg 825
38 Electric motor Driving motor  kw/60min 8
39 Hydraulic driving motor                                kw/5min 8.6
40 Control type  Electric driving             1
41 Operating pressure                     Hydraulic system pressure             kg/cm² 175
NOTE:  1.Drving AC choppedwave control mode /lifting AC voltage control mode





LTMA New arrival FB20 small battery charger operated forkliftLTMA New arrival FB20 small battery charger operated forkliftLTMA New arrival FB20 small battery charger operated forklift

Packaging & Shipping

 LTMA New arrival FB20 small battery charger operated forklift

Our Services

 2 ton electric forklift battery prices  After-sale service

We manufacturers,(LTMA) always treat the after-sale service more important than sale. Nowadays more than 10 agents around the world can supply LTMA professional after-sale service.

All the products of LTMA supplied with one year or 2000 workling hours (which occurs first) period quality warranty.

Detail clauses and policies please see to our website and product’s quality certificate.





Company Information

 LTMA New arrival FB20 small battery charger operated forklift



FAQ

 LTMA New arrival FB20 small battery charger operated forklift
