Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Pipe & Tube > ASTM A269 TP310S Seamless Stainless Steel Pipe
US$ 1 - 3
MOQ: 1000 Kilograms
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, DIN, EN, Other, AISI, ASTM, DIN, EN, SUS, ASME, ASME/ASTM/AISI/DIN/SUS ASTM A249/A213/A312
Place of Origin:
Shanghai, China
Brand Name:
ANBAO STEEL
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ASTM A249 TP304 Stainless Steel Welded PipeUS$ 1 - 3MOQ: 1000 Kilograms -
ASTM A269 TP304 Stainless Steel Welded PipeUS$ 1 - 3MOQ: 1000 Kilograms
-
ASTM A269 TP304L Stainless Steel Welded PipeUS$ 1 - 3MOQ: 1000 Kilograms
-
ASTM A269 TP321 Stainless Steel Welded PipeUS$ 1 - 3MOQ: 1000 Kilograms
-
ASTM A269 TP316 Stainless Steel Welded PipeUS$ 1 - 3MOQ: 1000 Kilograms
Standard
AISI, ASTM, DIN, EN, Other, AISI, ASTM, DIN, EN, SUS, ASME, ASME/ASTM/AISI/DIN/SUS ASTM A249/A213/A312
Place of Origin
Shanghai, China
Brand Name
ANBAO STEEL
Type
Other, Seamless, round and rectangular pipe
Steel Grade
300 Series
Application
general structure,gas and water transportation,boilers,heat exchangers
Certification
ISO
Thickness
0.5mm to 38.1mm
Outer Diameter
6mm to 1500mm
Specifications
ASTM A269 TP310S Seamless Stainless Steel PipeStandard:ASTM A249/A213/A269/A312
Grade:TP310S
Mill Certificate:EN 10204 3.1B
ASTM A269 TP310S Stainless Steel Seamless Pipe
Standard: ASME/ASTM/AISI/DIN/SUS ASTM A249/A213/A269/A312
Standard: ASME/ASTM/AISI/DIN/SUS ASTM A249/A213/A269/A312
Grade:201,304/304L,304H,316/316L,316Ti,317L,321/321H,309S,310S
Type: round and rectangular pipe
OD Size:6mm to 1500mm.
W.T. Size:0.3mm to 38.1mm.
Surface: Bright Anneal,Polished,Normal Surface,Sanitary Grade,Mirror grade
Normal Delivery State: Annealed and Pickling
Mill test certificate: according to EN 10204 3.1B
Usage:general structure,gas and water transportation,boilers,heat exchangers,super heaters, hydraulic system.
Chemical Composition
| Grade | Chemical Composition | ||||||||
| C max | Si max | Mn max | P max | S max | Ni | Cr | Mo | Others | |
| TP304 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 8-11 | 18-20 | ||
TP304H | 0.04 -0.10 | 0.75 | 2 | 0.04 | 0.03 | 8-11 | 18-20 | ||
| TP304L | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 8-13 | 18-20 | ||
| TP316 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11-14 | 16-18 | 2-3 | |
| TP316L | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 10-15 | 16-18 | 2-3 | |
| TP316Ti | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11-14 | 16-18 | 2-3 | Ti:5xC% |
| TP321 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 9-13 | 17-20 | Ti:5xC% | |
| TP347 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 9-13 | 17-20 | Nb+Ta: 10xC%-1.0 | |
| TP347H | 0.04 -0.10 | 0.75 | 2 | 0.04 | 0.03 | 9-13 | 17-20 | Nb+Ta: 8xC%-1.0 | |
| TP310 | 0.15 | 0.75 | 2 | 0.04 | 0.03 | 19-22 | 24-26 | ||
Tolerance
| Item | ASTM A213 | ASTM A312 | ASTM A269 | |||
| Diameter | O.D. | tolerance | O.D. | tolerance | O.D. | tolerance |
| <25.4 | ±0.10 | 10.3-48.3 | +0.4/-0.8 | <12.7 | +0.13/-0.13 | |
| 25.4-38.1 | ±0.15 | 48.3-114.3 | +0.8/-0.8 | 12.7-38.1 | +0.13/-0.13 | |
| 38.1-50.8 | ±0.20 | 114.3-219.1 | +1.6/-0.8 | 38.1-88.9 | +0.25/-0.25 | |
| 50.8-63.5 | ±0.25 | 219.1-457.2 | +2.4/-0.8 | 88.9-139.7 | +0.38/-0.38 | |
| 63.5-76.2 | ±0.30 | 457.2-660.4 | +3.2/-0.8 | 139.7-203.2 | +0.76/-0.76 | |
| 76.2-101.6 | ±0.38 | 660.4-864 | +4/-0.8 | |||
| 101.6-190.5 | ±0.38/-0.64 | 864-1219.2 | +4.8/-0.8 | |||
| 190.5-228.6 | ±0.38/-1.14 | |||||
| Thickness | O.D. | tolerance | ± 12.5%t | O.D. | tolerance | |
| ≤38.1 | +20%t/0 | ≤38.1 | ±15%t | |||
| >38.1 | +20%t/0 | >38.1 | ±10%t | |||
