Barbed Wire Machine
This machine can produce barbed wire which is widely used in national defence,military, railway,highway,agriculture,animal husbandry and other industries.The materials of barbed wire usually hot dipped galvanized wire,electric galvanized wire and PVC coated wire etc.
The advantage of this machine:saving materials and high capacity.
Technical Parameter
Model |
CS-A Type |
Motor power |
3kw |
Main drive shaft speed |
402r/min |
Wire diameter |
2.2mm-3.0mm |
Barbed wire diameter |
1.8mm-2.2mm |
Barbed space |
76mm(3’)/102mm(4’)/127mm(5’) |
Twisted number |
3-5 |
Theoretical production |
70kg/h |
Total Weight |
1200kg |
Main part size |
1950mm*950mm*1300mm |
Take-twisting part size |
1760mm*550mm*760mm |
Raw Material
The material barbed wire machine can be galvanized wire, PVC coated wire and so on.
Feature
It is light-style, easy to operate and high efficient, saving materials.
Product
We always pay more attention to the quality of our machine, Standard quality control system and team are responsible to insure the high quality in every process. We are devoted to producing a more efficiency and safer machines.
2. 24 hour technical support by e-mail
3. We offer installation and train the workers for the customers.
Our company is engaged in designing and exporting metal & wire mesh processing machinery, different kinds of wire mesh weaving machines and wire mesh welding machines. Our company is located in Shijiazhuang, Hebei, China. Our company has own factory - Hebei Jiake Welding Equipment Co., Ltd., which is located in the Industrial Zone of Anping, Hebei, China. Our company is a leading manufacturer of wire mesh machines in China and we always offer ADVANCED WIRE MESH TECHNOLOGY.
