Barbed wire machine
Barbed wire machine can produce barbed wire which is widely used in national defense, military, railway, highway, agriculture and other insustries. The materials of barbed wire are usually galvanized wire or PVC coated wire. The advantage of this machine are saving materials and high capactity.
Technical Parameter
Model |
CS-A Type |
CS-B Type |
CS-C Type |
Motor power |
3kw |
2.2kw |
2.2kw |
Main drive shaft speed |
402r/min |
355r/min |
355r/min |
Wire diameter |
2.2mm-3.0mm |
2.2mm-3.0mm |
1.6mm-2.8mm |
Barbed wire diameter |
1.8mm-2.2mm |
1.8mm-2.2mm |
1.6mm-2.2mm |
Barbed space |
76mm(3’)/102mm(4’)/127mm(5’) |
102mm(4’)/127mmm(5’) |
102mm(4inh)/127mm(5inch) |
Twisted number |
3-5 |
|
7 |
Theoretical production |
70kg/h |
40kg/h |
40kg/h |
Total Weight |
1200kg |
1000kg |
1000kg |
Main part size |
1950mm*950mm*1300mm |
|
|
Take-twisting part size |
1760mm*550mm*760mm |
|
|
Dimension |
|
3100mm*1000mm*1150mm |
3100mm*1000mm*1150mm |
1. It has advanced design and compact conformation.
2. It has attractive appearance.
3. It is easy and safe to operate.
2. 24 hour technical support by e-mail
3. We offer installation and train the workers for the customers.
Our company is engaged in designing and exporting metal & wire mesh processing machinery, different kinds of wire mesh weaving machines and wire mesh welding machines. Our company is located in Shijiazhuang, Hebei, China. Our company has own factory - Hebei Jiake Welding Equipment Co., Ltd., which is located in the Industrial Zone of Anping, Hebei, China. Our company is a leading manufacturer of wire mesh machines in China and we always offer ADVANCED WIRE MESH TECHNOLOGY.
