Home > Products > Marine Use Diesel Generator Set > 20-120kw weichai deutz diesel generator for boat
20-120kw weichai deutz diesel generator for boat
- 100 Set / Sets per Month
- Qingdao
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | U-power | Model Number: | 30GFD05 |
Output Type: | AC Three Phase | Speed: | 1500/1800RPM | Frequency: | 50/60HZ |
Rated Power: | 20-120kw | Rated Voltage: | 400/230V | Rated Current: | 36-216A |
Product Description
Specifications
20-120kw diesel generator1)Deutz engine
2)Standford Alternator
3)Environmental friendly and low noise
4)energy saving
The specification of deutz diesel generator set 20-120kw
1) Prime output: 20-120KW/25-150KVA
2) Max output: 22-132KW/27.5-165KVA
U-POWER Deutz D226B Series generating set matched D226B series engines made by Sino-Germany Venture—Weichai Power Co.,LTD.The alternators are world famous brands such as Stamford,Marathon and China alternators.
Model | Standby power | Rated output | Engine model | Alternator model |
KW | KW | |||
20GFD05 | 22 | 20 | D226B-3D | OEM Stamford |
22GFD05 | 24 | 22 | D226B-3D | OEM Stamford |
24GFD05 | 26.4 | 24 | D226B-3D | OEM Stamford |
25GFD05 | 27.5 | 25 | D226B-3D | OEM Stamford |
30GFD05 | 33 | 30 | TD226B-3D | OEM Stamford |
34GFD05 | 37.5 | 34 | TD226B-3D | OEM Stamford |
40GFD05 | 44 | 40 | TD226B-4D | OEM Stamford |
50GFD05 | 55 | 50 | TD226B-4D | OEM Stamford |
64GFD05 | 70.5 | 64 | TD226B-6D | OEM Stamford |
68GFD05 | 75 | 68 | TD226B-6D | OEM Stamford |
75GFD05 | 82.5 | 75 | TD226B-6D | OEM Stamford |
90GFD05 | 99 | 90 | TDB226B-6D | OEM Stamford |
100GFD05 | 110 | 100 | TDB226B-6D | OEM Stamford |
120GFD05 | 132 | 120 | TDB226B-6D | OEM Stamford |
Diesel Engine:
Engine model | Deutz 226B series |
Cylinder numbers | 3/4/6 |
Bore/stroke (mm) | 105/120 |
Min fuel consumption(g/kw.h) | ≤196 |
Cooling method | Closed water cooled |
Starting method | Electrical |
Speed governing method | Mechanical/Electronical(Optional) |
Intaking method | Natural aspiration / Turbocharged / turbocharged intercooled |
Type | Water cooling, in-line, four-stroke, humid cylinder liner, direct injection |
Alternator:
Alternator Model | OEM Stamford |
Voltage | 400 / 230V AC |
Frequency | 50Hz / 60Hz |
Power factor | 0.8lag |
Connecting method | three-phase & four wires |
Remarks | 1) Frequency: <3.0% |
Control system(Optional):
1) Automatic alarm system: acousto-optics test and alarm for start default,water over temperature, oil over temperature, over speed, oil over pressure and so on.
Standard supply:
1) Diesel engine standard supply
2) Alternator
3) Steel mounting base
4) Flange connector
5) Air cleaner, fuel cleaner, oil cleaner
6) On-board control panel
7) Shock absorber set
Optional Components:
Engine protection module, parallel equipment, common base oil tank, electric governor, automatic start, automatic transfer switch(ATS),remote- control equipment, sound-proof / weather-proof canopy, trailer type
Packing | plywood case |
Unit Price | FOB QINGDAO, |
Payment Terms | T/T30% deposit,after collection,arrange production.The 70% should be paid before the shipment.When got full payment,we release the full set of Original DOCS. |
Delivery Time | 10 working days after received 30%deposit |
MOQ | 1SET |
Warranty | 1year/1500hrs |
Above table is just a reference of our product, in fact we can manufacture diffetent kinds of diesel generator with different power and performance, we are sincerely looking for partners to develop oversea market together, any questions free to let
us know,your kindly feedbacks and suggestion will be highly appreciated.
