Home > Industrial Equipment & Components > Engine & Part > Engine > 4-cylinders Diesel Engine for Marine Used Price

4-cylinders Diesel Engine for Marine Used Price

4-cylinders Diesel Engine for Marine Used Price thumbnail-1
4-cylinders Diesel Engine for Marine Used Price photo-1
US$ 2,500 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Boat
Fuel:
Diesel
Contact Supplier Request Quote Chat Now
Weifang U-Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Usage Boat
Fuel Diesel
Stroke 4 Stroke
Cylinder Multi-cylinder
Cold Style Other, Water-cooled
Start Electric Start
Place of Origin Shandong, China
Brand Name WEICHAI
Model Number R6160
Dimension(L*W*H) 2435*967*1579mm
Weight 3350 (kg)
Certification CCS/BV/RS
Warranty one year
After-sales Service Provided Overseas service center available

Specifications

1) Super power performance,low speed.
2)energy saving,low emission
3)international warranty
4)CCS/BV certification


4-cylinders diesel engine for marine used price   4-cylinders diesel engine for marine used price

The speed of R6160 series is 1000r/mine with a power range of 164kw(223

hp)--255kw(350hp).

gear boxes can be applied to the engine sets with the speed ratio from 2:1 /2.5:1/3:1/3.5:1/4:1

R6160 seiries deisel engine is a new generation of 6160series which is developed by Weifang diesel engine factory in 2003 to meet the requirement of market. This product integrates the intemationally-advanced engine design conception with the 50-year-long engine manufacturing experience of Weichai, boasting wide power range, low consumption and excellent emission targets.

The design of the R6160 is based on the conception of better performance, lower consumption, convenient operation and people-oriented. The main alteration includes:

Optimizing and improving the fuel system, intake and exhaust system, cooling system, lubrication system on the basis of original 6160 series.

Adopting such advanced device as wet oil pan, eletrical pre-supply fuel pump, electric starting motor and sea-fresh water heat exchanger.

While iheriting strongpoint of the original 6160, the performance is improved and the fuel cosumption is lowered ( no more than 205g/kw.h).

The operation is simplified: there's no need to pump oil manually while atarting the engine.

This 6160 series diesel engine, designed out of brand new conception, has reached internationally advanced position.



Model List:



R6160 Series Marine Diesel Engine Model List
Engine Model   R6160A-2 R6160A-4 R6160A-6 R6160ZC R6160ZC4 R6160ZC2 R6160ZC380 R6160ZC408 R6160ZC450
Cylinder No. - 6 6 6 6 6 6 6 6 6
Bore/Stroke mm 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225
Displacement L 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14
Rated Power kW 164 184 202 255 220 255 280 300 330
Rated Speed r/min 1000 1000 1000 1000 1000 1000 1000 1000 1000
Srarting Method - Electric Electric Electric prneumatic motor Electric Electric Electric Electric Electric
Overhaul Period h ≥12000 ≥12000 ≥12000 ≥12000 ≥12000 ≥12000 ≥12000 ≥12000 ≥12000
Net weight kg 3350 3350 3400 3400 3400 3400 3400 3400 3400
Size
(LxWxH)		 mm 2435×967×1579 2435×967×1579 2562×967×1579 2644×967×1579 2644×967×1579 2644×967×1579 2644×967×1579 2644×967×1579 2644×967×1579





6160 Series Marine Diesel Engine Model List
Engine Model   6160A-1 6160A-121 6160A-12 6160A-123 6160A-125 6160A-13 6160A-13G 6160A-17 X6160ZC X6160ZC2 X6160ZC5 X6160ZC6?
Cylinder No. - 6 6 6 6 6 6 6 6 6 6 6 6
Bore/Stroke mm 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225 160/225
Displacement L 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14 27.14
Rated Power kW 90 110 124 136 147 164 184 202 220 255 220 255
Rated Speed r/min 750 850 750 850 850 1000 1000 1000 1000 1000 1000 1000
Srarting Method - compression air starting  Prneumatic Motor
Overhaul Period h 12000 12000 12000 12000 12000 12000 12000 12000 12000 12000 12000 12000
Net Weight kg 2400 2400 2450 2450 2450 2450 2450 2500 2500 2650 2650 2650
Size mm 2291×905×1345 2367×905×1425 2581×905×1424 2595×905×1454 2544×923×1458 2602×967×1461
(LxWxH)



4-cylinders diesel engine for marine used price



WHY CHOOSE US?
1)Ten years  experience,make us more  professional than other suppliers.
2)Quick delivery: 7-15 working days delivery time
3)Perfect after sale service: provide internatinal warranty service.
4)Pay attention to quality: 3 hours test before out factory
5) Environmental protection and energy saving : low noise, low emission,low fuel consumption.
6)Once establish business relationship in the long way, can share our VIP price.




Packing  plywood case

Unit Price FOB QINGDAO,
Payment Terms T/T30% deposit,after collection,arrange production.The 70% should be paid before the shipment.When got full payment,we release the full set of Original DOCS.
Delivery Time 10 working days after received 30%deposit
MOQ 1SET
Warranty  1year/1500hrs




Above table is just a reference of our product, in fact we can manufacture diffetent kinds of diesel engine with different power and performance, we are sincerely looking for partners to develop oversea market together, any questions free to let

us know,your kindly feedbacks and suggestion will be highly appreciated.



WEIFANG U-POWER CO.,LTD.
Hanting District,Weifang City,Shandong Province,P.R.China
TEL:0086-536-2222690  FAX:0086-536-2222661




 Reference picture
