Help Center20kw Ricardo Series Diesel Generator Set
Related Products
-
10kw Diesel Generating SetUS$ 3,000 - 10,000MOQ: 1 Set -
British R-series Diesel Generating Set in ChinaUS$ 2,000 - 6,000MOQ: 1 Set
-
Weichai WD Steyr Engine Generator SetUS$ 2,000 - 6,000MOQ: 1 Set
-
Cummings Diesel Engine Power Generator SetUS$ 2,000 - 8,000MOQ: 1 Set
-
100KW Ricardo Diesel Generator Set Foe ChinaUS$ 2,500 - 8,000MOQ: 1 Set
Specifications
Diesel Generator Set1)prime:20-150kw
2)4/6 cylinders,4 strokes
3)turbocharged,turbocharged intercooled,
4)water cooling
diesel generator
Land use
Selected Program:
Ricardo series
Prime output: 20-150KW/25-187KVA
Max output: 22-165KW/27.5-206KVA
Brief Introduction:
1) Prime output: 120KW/150KVA Genset
2) Engine model: R6105IZLD
Cyliner number: 6
Bore/stroke: 105/135mm
3) Alternator model: Stamford / Marathon/Landian
4) Cooling method: closed Water-cooled
5) Start method: Electrical
6) Speed governing method: Electronic
7) Intake method: Turbocharged/Turbocharged intercooled/Natural aspiration
8) 400 / 230V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires
9) Frequency: <3%
10) Frequency at stable state: <1.0%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%
15) Voltage return time: ≤4s
16) Voltage modulation: ≤0.3%
17) Control system:
a) Automatic alarm system: acousto-optics test and alarm for start default,water over temperature, oil over temperature, over speed, oil over pressure and so on.
b) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
18) Standard supply:
a) Diesel engine standard supply,
b) Alternator
c) Steel structure
d) Flange connector
e) Air cleaner, fuel cleaner, oil cleaner
f) On-board control panel
g) Set shock absorber
19) Optional Components:Engine protection module,parallel equipment,common base oil tank,electric governor,automatic start,automatic transfer switch(ATS),remote- control equipment,sound-proof / weather-proof canopy,trailer type.
