Specifications
diesel generating set1)Engine models: Ricardo,
2)Stamford,Marathon alternator,
3)ATS,AMF optional
4)Trailer,soundproof
Diesel generating set
Land use
Features:
1) Engine models: R4105 R6105 R6113,Deutz D226B
2) Alternator: Stamford, Leroy Somer, Marathon
3) Water-cooled
4) Output range: 24kW (30kVA) - 120kW (150kVA)
5) 8-hour operation base tank
6) Key start/auto start
7) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four-wire alternating
current output
8) Frequency: ≤3%
9) Voltage deviation at stable state: ≤±1%
10) Standard configuration of generator set:
a) Engine: Deutz diesel engine
b) Engine type: water-cooled, Humit cylinder liner, direct jection
11) Control system
a) Automatic alarm system: the unit has the acousto-optics alarm system
and arrestor for any situation when start defeats, water is over
temperature, oil pulls down, over speed, over load and over current
b) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
12) Starting system: DC alternator is used to start engine
13) Short circuit protection: MCCB air switch
14) Cooling system: combined cooling water tank fitted to meet requirements
of radiation at ambient temperature of 40°C
15) Filter system: oil, fuel and air filter
16) Accessories: exhaust elbow, bellow, muffler
