Help Center250kW Natural Gas Generator Set With Spark Plug
Related Products
-
200kW Natural Gas Generator Set With Spark PlugUS$ 5,000 - 450,000MOQ: 1 Set -
100kW Natural Gas Generator Set With Spark PlugUS$ 5,000 - 450,000MOQ: 1 Set
-
Supply Good Quality 15-300kw Natural Gas Generator SetsUS$ 3,000 - 800,000MOQ: 1 Set
-
High Quality Gas Generator SetUS$ 5,000 - 450,000MOQ: 1 Set
-
Weifang 25kw-300kw Gas Generator With CEUS$ 3,000 - 2,000,000MOQ: 1 Set
Natural Gas Generator/ Gas engine generator/ Gas generator set/ Gas generating set/ Gas engine genset/ Gas Genset /LPG Genset
Specification of 10-1000kw natural gas generator
1)Perfect All-Weather Service Property.
2)Outside steel owns preterable corrosion prevention capability.
3)Hard structure.
4)High-efficiency shock absorber can make sure that the generator set runs steadity.
5)energy saving 20%
Below is a model of our natural gas generator for reference.
| Gas Generator--50KW | |||
| Genset Model | SH-50GFZ | ||
| Genset Standby Power | 50KW | ||
|
Brand | Deutz | |
| Model | D226B-6CNG | ||
| Output Power | 55KW | ||
| Type | Direct Injection,Water-Cooled,Four stoke | ||
| Cylinder Numbers | 6 | ||
| Rated Speed (r/min) | 1500 | ||
| Ratio of compression | 12:1 | ||
| Bore/Stroke (mm) | 105*120 | ||
| Fuel | Natural gas or marsh gas | ||
| Starting Method | Electrical | ||
| Cooling Method | Water Cooled | ||
| Air Intake Method | Natural aspirated | ||
| Lubricating Method | Forced Lubricating | ||
| Alternator | Brand | Standford | |
| Voltage | 230/400V | ||
| Rated | 50HZ | ||
| Class of insulation | H | ||
| Voltage regulation method | AVR (automatic control) | ||
| Exciting Method | Brushless | ||
| Structure | Integral | ||
| Power Factor | 0.8 Lag | ||
| Connectiong Method | Three-phase & four-wires | ||
| Dimension(L*W*H) mm | 2240*790*1540 | ||
| Net weight(Kg) | 1650 | ||
| Payment Terms | T/T30% deposit,after collection,arrange production.The 70% should be paid before the shipment.When got full payment,we release the full set of Original DOCS. |
| Delivery Time | 7-15working days after received 30%deposit |
| MOQ | 1SET |
| Warranty | 1year/1500hrs |
| Packing | Plywood case or as customer required |
The chart just for an reference, we can produce genset from 10kw to 1000kw.
Engine mainly contain Cummins, Deutz, Steyr, Ricardo and Weichai series.
Alternator mainly contain: Marathon, Stamford
Rated Power from 10kva to 1000kva
Advantages:
1) Adopting advanced Hall ignition sensor and Highly capable ignition system, the engine ignition will be more reliable, and easier to start.
2) Main control parts are all the most advanced imported ones, to make more stable and reliable running.
3) Several gensets can be parallel connection or parallel net, which can increase the total power range. In addition,the gensets can take maintenance in different times,which will make little influence to the normal performance of gensets.
4) Low gas pressure is acceptable, no need to set up specified gas storage tank , which will save the investment and enhance the efficient output power .
5) Self-contained parts of gensets needs few accessories
6) Economical and low-cost running.
7) The fuel of gas reduces the accumulated carbon, which lessen the damage to between cylinder and valve, therefore, it will largely prolong lifetime.
8) The installation of high-quality control cabinet set enable mutiple protection, which enhance the safety for the running of gensets.
Standard Configuration
1. Ggas engine .
2. Alternator:AC brushless alternator 0.8LAG, IP22-23, Insulation class: H.
3. Control Panel.
4. Ignition system,including: ECU, Spark plug, High-voltage electricity wire;Ignition switch,Ignition coil;Wires.
5. Electronic speed regulator,including controller and actuator.
6. Solenoid valve
7. Flame arrester.
8. Hand valve
9. Zero pressure valves
10. Mixer.
11. Air filter.
12. Silencer
13. Remote radiator
14. Air circuit breaker (For the protecting purpose of overload, over current, etc)
15. Rubber anti-vibration pad between engine, alternator, control panel and base frame
16.Standard accessories, anti-vibration pad, exhaust pipe, maintenance tools kit, filters
17. Maintenance Operating manual, Quality certificate, Gen-sets ex-factory test report
Optional Configuration
1.ATS
2.Automatic start
3.CHP
4.Water heater and Oil heater
5.Synchronizing parallel cabinet
6.Grid Connection Cabinet
undproof canopy
Application area:
Natural gas generator : Pipeline natural gas, liquid natural gas (LNG),coal mine industry, crude oil industry
Biogas generator : dairy and poultry farm, food processing ( starch, alcohol, palm oil ),industrial waste, Bio garbage processing, landfill
LPG generator : Crude oil industry
Biomass generator: agriculture straw, wood chips etc.
Reference picture
Welcome to receive your any enquiry!
We will do our best to supply the best solution for your application!
