Home > Industrial Equipment & Components > Power & Generating Sets > Gas Generator > Supply Good Quality 15-300kw Natural Gas Generator Sets
US$ 3,000 - 800,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
U-POWER
Model Number:
MS,MT,MC
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Gas Generator SetUS$ 5,000 - 450,000MOQ: 1 Set -
Weifang 25kw-300kw Gas Generator With CEUS$ 3,000 - 2,000,000MOQ: 1 Set
-
10kw-1000kw Natural Gas Generator Sets for SaleUS$ 5,000 - 170,000MOQ: 1 Set
-
Parall 1000 kw Natural Gas Generator in Favorable PriceUS$ 2,000 - 10,000MOQ: 1 Set
-
1MW Natural Gas Generator Parallel to 4MW Power PlantUS$ 250,000 - 1,000,000MOQ: 1 Set
Place of Origin
China
Brand Name
U-POWER
Model Number
MS,MT,MC
Speed
1500rpm,1800rpm,3000rpm,3600rpm
Frequency
50/60Hz
Rated Power
15-300kw
Rated Voltage
400/230v,110/220v
Rated Current
18-1800A
| - High power and maximum efficiency - Low operating costs as a result of low levels of lubricant and fuel consumption as well as extended service intervals - Low emissions due to state-of-the-art combustion technologies - Low space requirement due to compact design - Reliable in use thanks to field-tested technology - Long service life resulting from application-specific design |
| Standard specification |
| Air inlet - Mounted air filter Gas/Ignition system - Air/Fuel mixer; automatic adjustment according to fuel gas characteristics - Individual cylinder ignition coils mounted direct to the spark plugs Lubrication system - Wet sump with filler and dipstick - Spin-on oil filter Cooling system - Thermostatically-controlled system with gear-drivencirculation pump and belt-driven pusher fan - Mounted radiator and piping - Guard for fan and rev parts Electrical equipment - 12/24 volt electric starter motors - Ecu control system - Battery base and power switch - Battery charger Exhaust system - Exhaust hose - Silencer (for industrial) Alternator - Automatic voltage regulator (AVR) Control system - DSE7220 control system - Air circuit breaker (MCCB) Mountings - Shock absorber - Manual Oil pump (For an oil change) Literature - User’s Handbook |
| GENSET DETAILS | |
| Genset Type | Silent type/Open type/Trailer Type Generators For Sale |
| Rated Power | From 10KVA to 1500KVA |
| Parameters | 50hz, 3ph, 400/230v, 1500rpm (60HZ can be made as request) |
| Fuel Consumption | ≤0.3m3/KW.h |
| Noise Level | 65-100 (db) |
| ENGINE DETAILS | |
| Engine Brand | Steyr (Deutz, ISUZU,CUMMINS is optional) |
| Cooling System | Water Cooled |
| Speed Governor | Electrical |
| ALTERNATOR DETAILS | |
| Alternator Brand | Stamford/Copy, Marthon, stamford, Brushless Alternator |
| Exciter Type | Self- excitation, Brushless with AVR |
| Insulation Class | H |
| Protection Grade | IP21(22- 23 is optional) |
| PACKAGE | |
| Packge | 1 SET/Plywood case |
| Delivery | 25 days after order confirmed |
| Payment terms | - 30% deposit (T/T),balance (70%) to be paid before shipment. (for bulk cargo) - 30% deposit (T/T),balance (70%) to be paid after receipt of the B/L copy(For container order) - L/C at sight. (For container order) |
| Warranty | - 1500hours/1year - During the guarantee period, we will supply freely the easy damaged parts for the possible problems except for the incorrect operation. - After expiration, we supply cost spare parts for genset maintenance |
| Standard Description: The DSE7210 is an Auto Start Control Module and the DSE7220 is an Auto Mains (Utility) Failure Control Module suitable for a wide variety of single, diesel or gas, gen-set applications. Monitoring an extensive number of engine parameters, the modules will display warnings, shutdown and engine status information on the back-lit LCD screen and illuminated LEDs. The DSE7220 will also monitor the mains (utility) supply. Both modules are compatible with electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engines and offer an extensive number of flexible inputs, outputs and engine protections so the system can be easily adapted to suit a wide range of application demands. Enhanced features include a real-time clock for improved event monitoring, the ability to display information in any language and a clear 4-line text display. The modules can be easily configured using the DSE Configuration Suite PC software. Selected front panel editing is also available.
|
Packaging & Shipping
Our Services
Customer satisfaction is our aim. We aim to our customers' satisfaction.
1, the domestic 10 service centers, 63 special service stations. All-weather, all-round, 24 hours a day throughout the year.
2, set up 22 service offices overseas, more than 100 special service stations, the establishment of overseas parts distribution center, forming a complete international service network
