Specifications
1.Size:0.20mm-5.00mm2.Class:130-220C
3.Enamel:PEW,UEW,EIW,EI/AIW
4.Features:Resistance to solvent,abrasion,heat shock,etc.
1.Compared to the enameled copper wire, the enameled aluminum wire has the following features, it is becoming more and more pouplar.
1).20°C higher heat resistance
2).easy to do the coil
3).good insulation property,has a longer service life
4).1/3 lighter than the copper,reduce the ocean freight
5). Most important, it can save you much purchase cost
2.Performance Features
Enameled aluminum wire ,High resistance to heat shock, high temperature and good performace at softening breakdown, suitable for highspeed automated routing, able to be direct weld, with no pinhole, resistive to high frequency, wearing, refrigerants and electronics corona, high breakdown voltage.small dielectric loss angle , dozens of times on pulse life as the ordinary compound enamel-insulated wire
3.Application:
Widely used in electrical tools, ballasts, automotive electronics, refrigerator and air conditioner compressor motors, television sets, electric stove, microwave ovens, various transformers, and other kinds of electronic coil motors, electrical appliances
4.Specifications of enameled aluminum wire :
Name |
enameled aluminum wire |
Diameter |
1.Round wire:Φ0.3-8.0mm 2.Flat wire: Thickness(a): Φ0.8mm-5.0mm, Width(b): Φ2-16mm |
|
Type |
Class 130 polyester enameled wire, PEW /130 |
Class 155 modified polyester enameled wire, PEW/155 | |
Class 180 polyesterimide enameled wire, EIW/180 | |
Class 200 polyester-imide / polyamide-imide enameled wire, EI/AIW200 | |
Class 130 /155/ 180 polyurathane enameled wire, UEW 130/ 155 /180 | |
Material |
Bare aluminium wire or squeeze bare flat wire confirm the National standard |
Standard |
IEC/NEMA/GB |
|
Typical applications:Electric motor, Instrument, Dry transformer, Generator, UPS power source, Electric welding machine, reactor,etc.
| |
5. Best service:
1) .Trail order is welcomed, you can test our quality before making large quantity.
2). We issued test reports for every shipment.
3). You can enjoy discounting and priority to produce first after you become to be our regular client.
