Specifications
wpc extrusion line1. CE, ISO certification
2. full automatic, can be PLC control
3. working stable,long service life
wpc door machinery
Discreption of wpc door machinery
1.The WPC wide board extrusion line is widely used in producing door by waste wood and PVC Powder.
2.The door from this line could be engraved, paintable, cuttable, etc. with characteristic of wood door.
Parameter of wpc door machinery
Description |
Parameter |
Feed material |
PVC+ wood powder+ assistant materials |
Production line speed |
0.8-1m/min |
Max. output |
350-700kg/h |
Outline size |
25× 2.5× 3 L× W× H(m), unsaturated |
Weight |
16T |
Total power |
260kw |
Actual energy consumption power |
210kw |
Consumed air |
0.4m 3 /min |
Atmospheric pressure |
0.6mpa |
Water cycle |
0.3m 3 /min |
Power |
AC380V± 10%, 50HZ |
Water |
Industrial water, no impurity, with filtration treatment, pressure: 0.4Mpa temperature: 14-25° C |
Work environment temperature |
0-40° C |
Consists list of wpc door machine
| 1. SJSZ92/188 or SJSZ 80/156 conical twin screw extruder | one set |
| 2.Mold for door--600,800, 900,1000,1200*(30-50mm ) | one set |
| 3.Vacuum calibration table | one set |
| 4.Pair Roll Haul Off Unit | one set |
| 5.Cutting uint | one set |
| 6.Conveying unit | one set |
| 7.Electric cabinet | one set |
| 8.Spare parts list | one set |
If you have requirements, please tell me anytime. We can according to your request to design and production.
