PVC plastic grinder/plastic pulverizer/plastic milling machine
- 20 Set / Sets per Month
- Shanghai
- T/T Credit Card
Product Details
Condition: | New | Type: | Grinder | Product Type: | Fertilizer |
Place of Origin: | Jiangsu, China | Brand Name: | Friendmachinery | Model Number: | Milling machine |
Certification: | CE ISO | Warranty: | 12 months, one year | After-sales Service Provided: | Overseas service center available |
Product Description
Specifications
1.High output,low consumption.2.Competitive price.
3.Warranty one year.
4.Easy coperate.
Performance Characteristics
The machine is our latest self-developed grinding mill; its features are as follows:
- Compared with similar grinders, its output is greatly improved (increased by 20%-50%) under the same power. It is energy-saving.
- The dust collector is added to effectively reduce dust pollution.
- The discharging of the main fan reduces labor intensity of operating workers.
- The door cover of the host can be opened for convenience of cutters.
- Wind and water cooling system are adopted to decrease the working temperature inside the machine body, so the grinded material uneasy for denaturalization and also conducive to grind heat sensitivity plastics. For example, the part of PE and ABS can be grinded by this machine.
- The powder mesh is adjustable (20-150mesh).
Main Technical Parameter
Blades Disk | 1,outer diameter: 483mm±1mm |
Tooth Plate | 1 set of 12 (High-quality alloy steel, the hardness of 55-58) |
Rotary Blade | 1 set of 24 (High-quality alloy steel, the hardness of 52-55) |
Main Motor Rev | 2950r/min |
Main Motor Power | 37 kw |
Draft Fan | 3kw |
Rotary Valve | 0.75kw |
Output | PVC 20-100 mesh 220-280 kg/h HDPE 20-80 mesh 60-150 kg/h |
Dimensions | 5900*1450*2900mm |
Weight | 1280 kg |
Mechanical Structure and Operational Principle
- The machine is composed of hopper, cabinet, main shaft, capstan, reclaiming fan blower, dust collecting machine, machine frame, motor, electric apparatus box and so on.
- Operating principle: the crashing materials get into the main frame through feeding skip. With the tail-wagging airstreams produced by the tail-wagging of the capstan, the grain-shaped materials tail-wagging in the crocus room, colliding with the board and cutting blades poignantly. After they are crashed, they were sent into dust-collecting bagging through reclaiming fan blower.
Contact Us
- Zhangjiagang Friend Machinery Co., Ltd.
- Contact nameWei Yuan
- Phone86-512-58551998, 18901568633
- AddressNo. 3, Jinle Road, Jinfeng Town
