Home > Products > Mill Machine > PVC milling machine miller powder pulverizer
PVC milling machine miller powder pulverizer
- 10 Set / Sets per Month
- shanghai
- T/T Credit Card
Product Details
Condition: | New | Type: | Other, Pulverizer, plastic milling machine | Product Type: | Detergent Powder |
Place of Origin: | Jiangsu, China | Brand Name: | Friendmachinery | Model Number: | SMF-400, SMF-400 |
Voltage: | according to request | Power(W): | according to request | Weight: | 600kg |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1 year |
Product Description
Haracteristics
- With water cycle and wind cooling, the machine can be applied into processing heat sensitive material.
- With the tail-wagging air stream (partly eddy flow) produced by the tail-wagging of the main shaft capstan of the machine, the input tail-wagging materials collide strongly with the board and the cutting blade, and was grinded into powdery (without sieving).
- Both the board and the cutting blade are made of abrasion-resistant steel, with excellent performance after heat treatment.
- With severeness of framework, the volume of the machine is quite small. If you open door closure, you can maintain it. It is completely airproof and without any dust leakage.
- With winding reclaiming equipment, the machine is features by cooling materials evenly, quick cooling and some other characteristics
1.Plastic Milling Machinedescription:
The unit is an ideal equipment of processing and milling thermal PVC,PE and other plastics. Though 20-30% milling powder is added into the processing formula, all physic chemistry characteristics of its product keep the ones while using full new raw material. It is a necessary equipment of using waste material, reducing cost and improving economic efficiency.
2.Main technical parameters :
Blades Disk | 1,outer diameter: 350mm±1mm |
Tooth Plate | 1 set of 30 (High-quality alloy steel, the hardness of 55-58) |
Rotary Blade | 1 set of 30 (High-quality alloy steel, the hardness of 52-55) |
Main Motor Rev | 2950r/min |
Main Motor Power | 30 kw |
Grinding Extent | 20-120 |
Output | PVC80-150 kg/h HDPE 20-80 mesh 60-150 kg/h |
Weight | 600kg |
If you are interested in our products ,pelase contact us take more inforamtion in any time.
