FBULDS-22 Ultra Long Distance Low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)

FBULDS-22 Ultra Long Distance Low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE) thumbnail-1
FBULDS-22 Ultra Long Distance Low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE) photo-1
US$ 0.02 - 0.2 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
FBELE, FBELE
Model Number:
FBULDS-22
Contact Supplier Request Quote Chat Now
Ningbo Best Group Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
NingBo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name FBELE, FBELE
Model Number FBULDS-22
Usage Other, Humidity Sensor, Temperature and Humidity Sensor Module
Theory Other, Hall Sensor, Temperature and Humidity
Output Other, Analog Sensor, Digital Sensor



FBULDS-22 Ultra long distance low Power Temperature and Humidity  Digital Temperature and Humidity Sensor Module(FBELE)



1.Specifications

Unique relative temperature and humidity sensor,excellent long term stability and ultra low power consumption.



2.Technical Specification

Power supply 3.3-5.5V DC
Output signal digital signal via Max Detect 1
Sensing element Polymer humidity resistor
Operating range 20-90%rH
Accuracy  +/-5%
Resolution or sensitivity 1%RH
Repeatability +/-2%RH
Humidity hysteresis +/-1%RH
Long-term Stability +/-1%RH/year
Interchangeability fully interchangeable



3.Description

FBUDLDS-22 output cailbrated digital signal.It applys exclusive digital-signal-collecting-technique and humidity sensing technology,assuring its reliavility and stavility. Its sensing elements is connected with 8-bit single-chip computer. Every sensor of this model id temperature compensated and calibrated in accurate calibration chamber and the calibration-coefficient is saved in type of programme in OTP menmory, when the sensor is detecting, it will cite coefficient from memory. Single-row packaged with four pins, making the connectiong very convenient.



4.Electrical Characteristics

Items Condition Min Typical Max Unit
Power supply DC 3.3 5 6 V
Current supply Measuring 1   1.5 mA
Stand-by 40 Null 50 uA
Collecting period Second   2   Second





FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)

FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)

FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE) FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE) FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE) FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)

FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)

FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)FBULDS-22 Ultra long distance low Power Temperature and Humidity Digital Temperature and Humidity Sensor Module(FBELE)

1.When can we get the reply?
Any inquiries will be replied within 24 hours.
Our SUNPHOR sales team will try our best to support you.

2.What about minimum order quantity?
We have no limit for MOQ,so you can even buy only 1 piece.
Welcome to buy sample to test first.

3.Do you have EU style adapter?
A: Yes,We have EU,UK and USA style adapter

4.Can customize,modify and develop products according to the design drawing?Yes,wprovide OEM service and can customize products according to the drawing.

5.How will you control product quality?
We strictly control every detail of production, and every product is inspected by our QC team before delivery. Moreover,our production is abided by ISO9000, 3C, CE and FCC.

6.What about delivery time?
Sample, We will send to you within 3 days after payment received. Production for big quantity needs 7 to 15 days. Andit also depends on product and quantity.
If want to know the exact time. Email us the quantity,

We will check the time for you.

7.What about terms of payment?
Payment terms: T/T, west Union Paypal and L/C etc.

8.How do I know that you have sent the products out?
Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times

9.How you will send the goods to us?
We will send the goods to you by DHL,FEDEX,UPS, EMS,AIR etc.
