High cost performance switching transformer
Application:Biochemical Analyzer,Microplate reader and other biological and chemical analysis instrument
Environmental conditions: Per Mil-STD-810E, Method 507.3
Surface quality:80/50 scratch/dig per Mil-O-13830A
Typical Wavelength:340,405,450,492,510,546,578,620, 630, 690, 700nm
Common Size: Φ12mm, Φ15mm, Φ25.4mm
Wavelength range in 200-3000nm and size in ∅4mm- ∅50mm are available upon request.
Product performance:Long life, high durability, high signal-to-noise ratio, optimal filter background can be less than 10-6(0.0001%)
Center wavelength(nm) |
FWHM(nm) |
Peak Transmission |
Average Blocking |
Size(mm) |
P/N |
220±2 |
8±2 |
15% |
OD5@200-1200nm |
Φ12 |
BF-220-01 |
254±2 |
8±2 |
15% |
OD5@200-1200nm |
Φ12 |
BF-254-01 |
282±2 |
8±2 |
25% |
OD5@200-1200nm |
Φ12 |
BF-282-01 |
340±2 |
8±2 |
40% |
OD5@200-1200nm |
Φ12 |
BF-340-01 |
405±2 |
8±2 |
40% |
OD4@200-1100nm |
Φ12 |
BF-405-01 |
450±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-450-01 |
480±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-480-01 |
492±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-492-01 |
505±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-505-01 |
510±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-510-01 |
546±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-546-01 |
578±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-578-01 |
620±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-620-01 |
630±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-630-01 |
670±2 |
8±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-670-01 |
700±2 |
10±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-700-01 |
750±2 |
10±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-750-01 |
760±2 |
10±2 |
50% |
OD4@200-1100nm |
Φ12 |
BF-760-01 |
