Home > Products > titanium wire > Astm B863 polished titanium welding wire
Astm B863 polished titanium welding wire
- 1000 Kilogram / Kilograms per Month
- shanghai for titanium wire
- T/T Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | dongfu titanium | Application: | industrial,medical |
Wire Gauge: | 0.7-7mm | Grade: | titanium | Ti (Min): | 89.5 |
Strength: | 240 |
Product Description
Astm B863 polished titanium welding wire
Titanium wires | |||
Grade Status Specifications | Grade | Diameter/mm | Supply status |
Gr1,Gr2,Gr3,Gr4 Gr6,Gr7,Gr12,TA28 TC1,TC2,TC3 | 0.1~7.0 | Heat processing(R) Cold processing(Y) Annealed(M) | |
TA1-1,TC4EL1 Gr5(Ti-6AL-4V) | 1.0~7.0 | ||
Material | Pure titanium or alloy titanium. | ||
Standard | ASTM B348,ASME SB348,ASTM F67,ASTM F136,ASTM B863, ASTM 2965,ASTM 3623,GB/T 2965-2007,GB/T 3623-2007 | ||
Features | Low density,high strength,excellent corrosion resistance,good thermal stability and conductivity. | ||
Applications | As electrode materials,fasteners,welding materials,medical field, surgical implants,chemical industry, structural parts,glasses, etc. | ||
Shape | Coiled or straight | ||
Package | Carton or wooden case. | ||
Quality and test | All of the products are detected by ultrasound making sure that no defects inside the products. Besides , chemical composition, mechanical properties and high-powered organization are also strictly controlled,ensuring our clients get the best products. |
chemical composition
N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti | |
Gr 1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal |
Gr 2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal |
Gr 3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal |
Gr 4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | bal |
Gr 5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
Gr 7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
Gr 9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
mechanical property
grade | Tensil strength(min) | Yeild strength(min) | Elongation(%) | ||
ksi | MPa | ksi | MPa | ||
1 | 35 | 240 | 20 | 138 | 24 |
2 | 50 | 345 | 40 | 275 | 20 |
3 | 65 | 450 | 55 | 380 | 18 |
4 | 80 | 550 | 70 | 483 | 15 |
5 | 130 | 895 | 120 | 828 | 10 |
7 | 50 | 345 | 40 | 275 | 20 |
9 | 90 | 620 | 70 | 438 | 15 |
12 | 70 | 438 | 50 | 345 | 18 |
PACKING
1. Wooden case, free of fumigating;
2. Steel pallet + wooden case (above 1 ton/case);
3. Available upon the client's request.
SHIPPING
1. Air express (FedEx, UPS, DHL & EMS);
2. Air transport;
3. Sea transport;
4. Sea-land transport.
1. OEM service, MOQ 1 piece acceptance
2. Satisfy your required material tests
3. Effectiveness: Enquiries and questions shall be solved with 24 hours
4. Expertise: Devoted to Nonferrous metals of titanium, nickel, zirconium pipe, fittings for years.
5. Facilities: The machines and tools are made for Ti, Ni, Zr pipe, fittings processing.
6. The authorized third party products approval
7. Fast manufacturing time, delivery.
We need below information to quote for you:
1. Product Name
2. Standard
3. Material Grade (Chemical Composition)
4. Dimension
5. Quantity
6. The Drawing for Special Parts
If you have any interests, please don't hesitate to inquiry.
We welcome the sample order. Thank you.
