Aerial Platform Clination Switch Sensorreverse Polarity & Over Loading Short Circuit Protection

cartons

Specifications

Aerial platform clination switch sensor ,reverse polarity & over loading short circuit protection

General Description:

SCA130T is a dual-axis level switch (Aerial platform tilt switch control & leveling)which is researched and produced by Shenzhen RION with high accuracy and high stability ,Its Measuring range is±90°, The switch action points and trigger delay time can be output and set through the RS232  serial communication port. It has ZERO setting function and response frequency adjustment function as well as optional Baud rate. It can be widely used in engineering mechanism field.

Features:
1:Two-axis inclinometer
2:Customers can self-set switch alarm values
3:ZERO setting function
4:DC 9~36V wide voltage power supply
5:Multi-Measuring range
6:Four channel switch signal and RS232 outpout
7:Full Metal Jacket,IP98 protection
8:Entirely industrial parts of appratus,stable and credible performance
9:Shockproof>20000g
10:Small volume,light weight
11:reverse polarity protection,over loading short circuit protection.
12:transistor drive,OC door output
13:small size(91*40*26mm)

Applications:
1:Chain Block,Hoist,Crane.
2:Aerial Platform Vehicle,lifter
3:Automatic orientation platform
4:Mining mechanism,oil-well drilling equipment
5:Security control,monitor,alarm

,
