Specifications
Inclinometer Module1. High performance
2. Wide voltage input
3. Stable & reliable Long term working
4. Customized
SCA1500 Voltage Output Inclinometer Single Board Dual Axis Inclinometer Module Analog Voltage Output
General Description
SCA1500T is a dual axis inclinometer module with analog voltage output, built-in micro solid pendulum into angle changes by measuring the static gravity field changes then convert into inclination change, the changes in mode output voltage (0-5V),mainly used to measure the inclination of the object with respect to the horizontal plane.
Resolution is 0.01 deg,accuracy specification please refer to the page 3 of product technical data .
This product uses non-contact measurement principle, can real-time output current posture inclination,Simple to use, and no need to retrieve the relative changed surface to install.Latest MEMS inclinometer productive technology production, high-precision, small size, strong resistance to external electromagnetic interference ability, the ability to withstand shock and vibration. It is the ideal choice for industrial equipment, platform measuring attitude!
Features
Dual-Axis Inclinometer(Single axis are optional) Measuring Range : ±1~±90° optional
Accuacy: refer to the technical data DC 5V voltage input
Output interface :0~5V Wide temperature working: -40~+85°C
Resolution: 0.01° Small Volume : 30×30×3.5mm(customized)
Application:
Engineering vehicles automatic leveling Bridge & dam detection
Aerial platform vehicle,lifter safety & protection Medical facilities angle control
Underground drill posture navigation Shield pipe jacking application
Based on the angle direction measurement Geological equipment inclined monitoring
Directional satellite communications antenna pitching angle measurement
Ordering information:
Item No. |
Description |
Output corresponding: 0V-5V |
SCA1500-XXX |
Note: XXX means angle measuring range optional number XXX from10deg~90deg range optional |
|
Parameter
