Long-life Strong Stability Industry Electronic Gyroscope From Shenzhen Rion Company
General Description
TL610D is a gyroscope (angle rate sensor)based on the micro mechanical principle,a miniature inertial devices for mainly measuring the angular velocity of a moving object. Product internal withthe silicon ultrafine precision ring sensing technology so that it has a high-performance, waterproof,anti-vibration, light weight,anti-electromagnetic interference characteristics and etc. Uninterrupted the machine with self-test technology, the filtering algorithm and the first time in the country by eliminating resonance technology to solve the influence on data because of the surrounding noise or vibration interference source to the ordinary gryoscope. TL610D add another new temperature sensor compensation technology to solve the temperature drift impact problems,with over-temperature stability and long life characteristics etc. to realizethe domestic similar products technology-leading technology.
Products with high cost-effective, small volume,more advantages than the FOG in application fields, is now widely used in the automotive, military, marine, moving objects, position control & attitude control, and other applications that require precise angle measurement occasions!
Key Features
1.High performance drift stability
2.Low noise
3.Light weight
4.Long life,strong stability
5.Cost-effective
6.Excellent vibration performance
7.All solid state
8.Compact & light design
9.0~5V voltage output
10.Wide temperature range
11.DC+9~36V power supply Temperature drift< ±0.2°/sec
Application
1.Military & Industry
2.Navigation
3.Car navigation
4.Platform stability
5.Auto safety system
6.Remote control helicopters
7.Turck-mounted satellite antenna equipment
8.Industrial control
9.Equipments
10.PS combination
11.Camera stability
12.Robot
13.3D virtual reality
14.Ships electronic needle error compensation on inclined(angle rate)inductioni equipment
Paramters
Measuring range (°/s) |
±50 |
±150 |
±300 |
Measuring axis |
X,Y,Z(optional) |
X,Y,Z(optional) |
X,Y,Z(optional) |
Bandwidth(Hz) |
>2000 |
>2000 |
>2000 |
Resolution(°/s) |
0.1 |
0.1 |
0.1 |
Nonlinear |
0.1% of FS |
0.1% of FS |
0.1% of FS |
Temperature drift °/sec |
< ±0.1°/sec,/℃
|
< ±0.1°/sec,/℃
|
< ±0.1°/sec,/℃
|
Start time(ms) |
5 |
5 |
5 |
Input voltage(V) |
+9~36V |
+9~36V |
+9~36V |
Output voltage(V) |
0~5V |
+0~5V |
0~5V |
Current(mA) |
6 |
6 |
6 |
Working temperature (℃) |
-40 to +85 |
-40 to +85 |
-40 to +85 |
Store temperature (℃) |
-55to +100 |
-55to +100 |
-55to +100 |
Capacitive load(Pf) |
1000 |
1000 |
1000 |
Shock(g) |
5g~10g |
5g~10g |
5g~10g |
Impact(g) |
200g pk,2ms,½sine |
200g pk,2ms,½sine |
200g pk,2ms,½sine |
Time Drift |
20°/h |
||
Working life |
11 years |
11 years |
11 years |
Electromagnetic compatibility |
According to EN61000 and GBT17626 |
||
MTBF |
≥50000hours/times |
||
Insulation resistance |
≥100M |
||
Shockproof |
100g@11ms,3Times/Axis(half sinusoid) |
||
Anti-vibration |
10grms,10~1000Hz |
||
Protection class |
IP67 |
||
Connector |
5 pins air-plug, matched with 1M cable |
||
Weight |
110g(Without cable) |
||
Our Company & Workshop View :
Certificates & Test Reports :
We can offer :
- Reliable high quality products and services
- Perfect whole system application solution
- Strong technical support before or after sales service
- Extend strong sales teams & distributors global
- OEM products as buyer's requests
Our main products :
- Single/Dual-axis High accuracy Inclinometer (digital , current , voltage, CAN output type etc. )
- 2D / 3D Electronic Compass Sensor (RS232, RS485,TTL output, etc.)
- 1-Axis , 2-Axis, 3-Axis Accelerometer (digital , current , voltage output, etc.)
- 1-Axis , 2-Axis, 3-Axis Gyroscope((digital , current , voltage output, etc.)
- Single /Dual / Three-Axis Angular Gyro Sensor (RS232, RS485,TTL output, etc.)
- High performance MEMS Mini AHRS ( Attitude Heading Reference System )
- Other Agent Products PNI...etc
Order Process :
Before order pls contact us for confirm detailed informaiton such as model ,price ,lead time ...etc
Payment ways :
T/T, WU or Paypal;
Delivery methods & Time :
DHL takes 3-5days , Fedex takes 2-7 days , UPS takes 3-7day , EMS takes 10-25days ;
Quality Policy :
We gurantee 1 year in free charge .
Storage :
Note usually we don't make any items in stock , samples customize time need around 3-7days .
