Specifications
MEMS Tilt Sensor1.Measuring Range : +/-1 ~+/-30deg
2.Output interface :0~5V
3. Accuracy : 0.002deg
4.High Resolution: 0.
Wholesales & Retails ACA620T High Accuracy Dual-Axis Analog MEMS Tilt Sensor Position Sensor
General Description
ACA620T is a high precision & full temperature compensation dual-axis inclinometer with analog voltage output, high-precision 24bit A / D differential converter inside the product, to ensure the the products output voltage signal linearity, and users no need to do linearity correction by themselves in the future , install then to use, stability and reliability ! In addition, because of ACA620T system integrates high-resolution temperature sensor, with the MCU central processing system secondary temperature compensation, full temperature zero drift can be controlled to 0.0008 °/°C ,normal temperature small measuring range the most accurate up to 0.002 °, in domestic the counterparts products with absolute competitive advantage.
Non-contact installation features make ACA610T with superior system integration, Simply fix the sensor on the measured surface by screws , then can automatically calculate the object posture inclination, easy to operate, easy to install. Newest MEMS high-technology for production , high-precision, small size, with strong ability resistance to external electromagnetic interference and to withstand shock and vibration, has been widely used in the industrial and military fields!
Features
- Dual-Axis Inclinometer
- Measuring Range :±1~±30° optional
- Accuracy: refer to the technical data
- Wide voltage input: 9~36V
- Wide temperature working: -40~+85°C
- IP67 protection class
- Highly anti-vibration performance >2000g
- High Resolution: 0.001°
- Temperature drift 0.0008°/°C
Application:
- Engineering vehicles automatic leveling
- Bridge & dam detection
- Precise instrument level control
- Medical facilities angle control
- Underground drill posture navigation
- Railway gauging rule , gauge equipment leveling
- Based on the angle direction measurement
- Geological equipment inclined monitoring
- Directional satellite communications antenna pitching angle measurement
