NdFeB Strong Disc Magnets D5.0 x 1.0mm N35 Nickel Coated

NdFeB Strong Disc Magnets D5.0 x 1.0mm N35 Nickel Coated thumbnail-1
NdFeB Strong Disc Magnets D5.0 x 1.0mm N35 Nickel Coated photo-1
US$ 0.01 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Ningbo Bestway
Model Number:
BWND
Contact Supplier Request Quote Chat Now
Ningbo Bestway Magnet Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Ningbo Bestway
Model Number BWND
Composition Neodymium
Product Type Rare Earth Magnet
Application Industrial Magnet
Grade Neodymium-Iron-Boron, N35

Specifications

Strong Disc Magnets
1.High quality consistency
2.Excellent anti-corrosion properties
3.SST: 48/72hours
4.Low weight loss

Strong Disc Magnets



Product Description

Strong Disc Magnets /NdFeB Disc Magnets/Neodymium disc magnet/NdFeB magnet disc

 Product Name:  NdFeB Strong Disc Magnets D5.0 x 1.0mm N35 Nickel coated

Material: NdFeB (Neodymium Iron Boron)

Shape: Disc

Diameter: 5mm

Height: 1mm

Tolerance in size: +/-0.1mm

Direction of magnetisation: axial (parallel to height)

Type of coating: Nickel (Ni-Cu-Ni)

Weight:  about 0.1472g/pcs

Grade: N35

ing temperature: 80°C

Residual Magnetism Br: 11.7-12.2 KGs, 1.17-1.22 T

Coercive field strength bHc: 10.8-11.5 KOe,860-915 KA/m

Coercive field strength IHc: ≥12 KOe,  ≥ 955 KA/m

Energy product (BH)max: 33-36 MGOe, 263-287KJ/  m³

Free of harmful substances according to ROHS Directive 2002/95/EC

Exempt from registration according to REACH.



If the above size is not exactly size you required, pls send inquiry to us including the size, the grade of material ,the coating and the quantity , we will send our best price for your reference.





Company Information



NdFeB Strong Disc Magnets D5.0 x 1.0mm N35 Nickel coated



Packaging & Shipping

 NdFeB Strong Disc Magnets D5.0 x 1.0mm N35 Nickel coated



Please kindly contact us for free if you want to wholesale this magnet, Thank you!
