halal chickens slaughtering equipment for abattoir house

Name: halal chickens slaughtering equipment for abattoir house
Brand: ONESTOP
Availability: InStock

FOB Price

USD $550,000 - $650,000 / Set

1 Set(Min.Order)

Port Qingdao

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Poultry
Place of Origin	Shandong, China	Brand Name	ONESTOP
Model Number	N/M	Voltage	220V/380V
Power(W)	1500W	Dimension(LWH)	Chicken Slaughtering Machine
Weight	1500kg	Certification	ISO
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

1000Chickens/h Slaughter and Parting Line

1000 Chickens per hour Slaughter&Cutting Line Equipment List


No.	Items	Model	Unit	Quantity	Remarks
I. Slaughter/Scald/Defeather Section
1	Hanging conveyor for slaughter	L=88m	set	1	Hook space: 6 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included.
2	Waterbath stunning machine (Larger size)		set	1	SUS frame, fiberglass groove
3	Air drum type scalding machine (Larger size)	Full closed	set	1	Length:3.3m, scalding time:1minute; It includes SUS air drived stirring system, 1 air blower, SUS poultry baffle, SUS shell and steam enclosed cover, SUS rail and corner wheel, water level and temp auto control system;
4	Vertical defeathering machine	6 rows with 8 plates each row	set	1	Adjustable SUS frame, two parallel cabinets; total 6 rows with 8 plates each row, each plate has 12 rubber whips; 6 belt drive devices, 6 high speed chinlon belts, feather baffle and SUS spray pipe are included;
5	Hook washing machine (larger size)		set	1	SUS frame, 2 nylon brushes and motor drive, 2 SUS brush cabinet and spray pipes
6	Automatic poultry unhooking device		set	1	Made from SUS
7	Carcass chute		set	1	Made from SUS
8	Electric control cabinet	DK-1	set	1	Used to control the drive equipments in this section
II. Evisceration Section
1	Evisceration hanging conveyor	L=32m	set	1	Hook space: 8 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included.
2	Evisceration reception chute		pc	4	SUS chute and frame with adjustable legs
3	Carcass washing device		pc	1	Frame, shell and pipes are made from SUS
4	Electric control cabinet	DK-4	set	1	Used to control the drive equipments in this section
III. Pre-cooling Section
1	Spiral pre-cooling Machince(Larger size)	L=9m	set	1	Screw diameter:1.8m, including chute, SUS tank and frame, SUS screw propulsion device, auto poultry output system, air-blast system and air blower, motor reducer; Cooling media: cold water or brash ice(cold water chilling unit and slice ice machine)
2	Carcass reception chute	L=2m L=3m	set	2	SUS chute and frame
3	Electric control cabinet	DK-4	set	1	Used to control the drive equipments in this section
Sub-total:
IV. Cutting Section
1	Hanging conveyor for cutting	L=45m	set	1	Hook space: 8 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included.
2	Worktable	1800×900×800	pc	15	SUS frame and adjustable legs, and SUS worktable
3	Electric control cabinet	DK-3	set	1	Used to control the drive equipments in this section
IV. Installation materials cost (Mainly major steel beams, hanging,materials, etc.): Total 15t,buyer can source at your local, we give the drawing or buying from us.
V. Installation fees: Including the worker's round tickets, salary $100/day/person, Accommodation.
VI. Transportion Cost: To be discussed.
